Запчасти Komatsu WA420-3MC FIG. K-A СИДЕНЬЕ ОПЕРАТОРА - VINYL КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

423-960-A050

SEAT ASSEMBLY, VINYL - 515

SN: A31001-UP-UP

1шт.

|$1

421-960-A610

KIT, UPPER ASSEMBLY

SN: A31001-UP-UP

1шт.

1

195-57-A0200

KIT, FRAME ASSEMBLY

SN: A31001-UP-UP

1шт.

2

195-57-A0220

KIT, LUMBAR SUPPORT

SN: A31001-UP-UP

1шт.

3

195-57-A0300

KIT, BACK FOAM

SN: A31001-UP-UP

1шт.

4

421-960-A620

KIT, BACK COVER

SN: A31001-UP-UP

1шт.

5

195-57-A0500

KIT, SEAT FOAM

SN: A31001-UP-UP

1шт.

6

195-57-A1400

KIT, SEAT COVER

SN: A31001-UP-UP

1шт.

7

421-960-A360

KIT, HANDLE - GRAY

SN: A31001-UP-UP

1шт.

8

206-57-A1470

KIT, RECLINER CABLE

SN: A31001-UP-UP

1шт.

9

195-57-A0800

KIT, HEIGHT RISER ASSEMBLY

SN: A31001-UP-UP

1шт.

10

195-57-A0900

KIT, HEIGHT RISER LATCH

SN: A31001-UP-UP

1шт.

11

195-57-A0010

KIT, HEIGHT RISER SPRING

SN: A31001-UP-UP

1шт.

12

421-960-A340

KIT, SUSPENSION ASSEMBLY

SN: A31001-UP-UP

1шт.

13

421-960-A310

KIT, DAMPER

SN: A31001-UP-UP

1шт.

14

195-57-A0210

KIT, WEIGHT ADJUSTER

SN: A31001-UP-UP

1шт.

15

195-57-A0310

KIT, UPSTOP/BUMP STOP

SN: A31001-UP-UP

1шт.

16

195-57-A0020

KIT, SINGLE SPRING BEARING

SN: A31001-UP-UP

1шт.

17

195-57-A0120

KIT, LEVER/CENTER PIVOT

SN: A31001-UP-UP

1шт.

18

421-960-A350

KIT, SLIDERAIL

SN: A31001-UP-UP

1шт.

19

421-960-A370

KIT, SUSPENSION COVER

SN: A31001-UP-UP

1шт.

20

195-57-A1420

KIT, HEADREST

SN: A31001-UP-UP

1шт.

21

421-960-A430

KIT, L.H. ARMREST

SN: A31001-UP-UP

1шт.

|$23

421-960-A440

KIT, R.H. ARMREST

SN: A31001-UP-UP

1шт.

22

BRACKET, L.H. (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.

23

BRACKET, R.H. (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.

24

BOLT (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.

25

SCREW (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.
