Запчасти Komatsu WA420-3MC FIG. K-A СИДЕНЬЕ ОПЕРАТОРА - ВОЗД. RIDE КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

423-960-A040

SEAT ASSEMBLY, COMPRESSED AIRRIDE - 555

SN: A31001-UP-UP

1шт.

|$1

421-960-A210

KIT, UPPER ASSEMBLY - CHARCOAL FABRIC

SN: A31001-UP-UP

1шт.

1

195-57-A0200

KIT, FRAME ASSEMBLY

SN: A31001-UP-UP

1шт.

2

421-960-A360

KIT, HANDLE

SN: A31001-UP-UP

1шт.

3

195-57-A0220

KIT, LUMBAR SUPPORT

SN: A31001-UP-UP

1шт.

4

195-57-A0300

KIT, BACK FOAM

SN: A31001-UP-UP

1шт.

5

421-960-A220

KIT, BACK COVER - CHARCOAL FABRIC

SN: A31001-UP-UP

1шт.

6

195-57-A0500

KIT, SEAT FOAM

SN: A31001-UP-UP

1шт.

7

195-57-A0400

KIT, SEAT COVER - CHARCOAL FABRIC

SN: A31001-UP-UP

1шт.

8

195-57-A0800

KIT, HEIGHT RISER ASSEMBLY

SN: A31001-UP-UP

1шт.

9

195-57-A0900

KIT, HEIGHT RISER LATCH

SN: A31001-UP-UP

1шт.

10

195-57-A0010

KIT, HEIGHT RISER SPRING

SN: A31001-UP-UP

1шт.

11

206-57-A1470

KIT, RECLINER CABLE

SN: A31001-UP-UP

1шт.

12

421-960-A310

KIT, DAMPER

SN: A31001-UP-UP

1шт.

13

421-960-A450

KIT, 24 V COMPRESSOR SUSPENSION ASSEMBLY

SN: A31001-UP-UP

1шт.

14

421-960-A350

KIT, SLIDERAIL

SN: A31001-UP-UP

1шт.

15

195-57-A0310

KIT, UPSTOP/BUMP STOP

SN: A31001-UP-UP

1шт.

16

421-960-A460

KIT, AIR SPRING

SN: A31001-UP-UP

1шт.

17

421-960-A470

KIT, SUSPENSION COVER

SN: A31001-UP-UP

1шт.

18

421-960-A480

KIT, 24 V COMPRESSOR/VALVE

SN: A31001-UP-UP

1шт.

19

421-960-A490

KIT, BEARING

SN: A31001-UP-UP

1шт.

20

421-960-A510

KIT, LEVER/CENTER PIVOT

SN: A31001-UP-UP

1шт.

21

421-960-A430

KIT, L.H. ARMREST

SN: A31001-UP-UP

1шт.

|$23

421-960-A440

KIT, R.H. ARMREST

SN: A31001-UP-UP

1шт.

22

BRACKET, L.H. (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.

23

BRACKET, R.H. (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.

24

BOLT (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.

25

SCREW (SEE FIG. K0110-01A0)

SN: A31001-UP-UP

-1шт.

26

419-06-A2210

HARNESS, WIRING

SN: A31001-UP-UP

1шт.

N/I

08037-01008

GROMMET

SN: A31001-UP-UP

1шт.

N/I

08022-04001

CONNECTOR

SN: A31001-UP-UP

1шт.

N/I

08021-00400

CONNECTOR

SN: A31001-UP-UP

1шт.

|$32

-1шт.

|$33

F1 - REPLACEMENT OF CENTER PIVOT BEARINGS REQUIRES REPLACEMENT OF ITEM 18.

-1шт.

|$35

-1шт.

|$36

F2 - THIS KIT IS REQUIRED TO SERVICE THE CENTER PIVOT BEARING ON UNITWITH WELDED PIVOT PINS.

-1шт.

|$37

-1шт.
