Запчасти Komatsu WA420-3MC FIG. F-A ТРАНСМИССИЯ - ПЕРЕД. И ПЕРВ. SPEED МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION ASSEMBLY(SEE FIG. F4350-51A0)

SN: A31001-A31044-UP

-1шт.

|$2

OR

-1шт.

|$4

TRANSMISSION ASSEMBLY(SEE FIG. F4350-51A0)

SN: A31045-UP-UP

-1шт.

|$5

714-17-12010

CLUTCH ASSEMBLY, FORWARD AND 1ST SPEED

SN: A31001-UP-UP

1шт.

1

714-17-12110

SHAFT ASSEMBLY

SN: A31001-UP-UP

1шт.

2

714-07-12911

PISTON, FORWARD

SN: A31001-UP-UP

1шт.

3

714-07-12661

PISTON, 1ST

SN: A31001-UP-UP

1шт.

4

714-07-12670

DISC

SN: A31001-UP-UP

6шт.

5

714-07-19720

DISC

SN: A31001-UP-UP

10шт.

6

714-07-12680

PLATE, SEPARATE

SN: A31001-UP-UP

18шт.

7

714-07-12691

SPRING, WAVE

SN: A31001-UP-UP

10шт.

8

714-07-12781

SPRING, WAVE

SN: A31001-UP-UP

6шт.

9

714-07-12711

PLATE, END

SN: A31001-UP-UP

2шт.

10

714-07-12720

RING, SNAP

SN: A31001-UP-UP

2шт.

11

714-07-19320

RING, SEAL

SN: A31001-UP-UP

2шт.

12

714-08-19220

RING, SEAL

SN: A31001-UP-UP

1шт.

13

714-07-12740

RING, SEAL

SN: A31001-UP-UP

1шт.

14

714-07-12220

WASHER, THRUST

SN: A31001-UP-UP

4шт.

15

714-07-12250

SPACER

SN: A31001-UP-UP

2шт.

16

56B-15-19420

BEARING, NEEDLE

SN: A31001-UP-UP

3шт.

17

714-17-12410

GEAR, 49 TEETH - FORWARD

SN: A31001-UP-UP

1шт.

18

714-07-12760

GEAR, 26 TEETH - 1ST

SN: A31001-UP-UP

1шт.

19

06040-06315

BEARING

SN: A31001-UP-UP

1шт.

20

06043-00315

BEARING

SN: A31001-UP-UP

1шт.

21

714-07-12290

RING, SEAL

SN: A31001-UP-UP

3шт.
