Запчасти Komatsu WA420-3L FIG. E-A ЭЛЕКТРИКА - ЗАДН. LIGHTS ЭЛЕКТРИКА

1

421-06-23210

LIGHT ASSEMBLY, COMBINATION

SN: A30001-UP-UP

1шт.

|$1

08104-12420

BULB, 25/10 W

SN: A30001-UP-UP

1шт.

|$2

08105-12420

BULB, 25 W

SN: A30001-UP-UP

2шт.

|$3

421-06-23220

LENS

SN: A30001-UP-UP

1шт.

|$4

08056-00671

CONNECTOR

SN: A30001-UP-UP

1шт.

2

01220-40535

SCREW, MOUNT LENS

SN: A30001-UP-UP

4шт.

3

42A-06-13160

NUT, MOUNT LENS

SN: A30001-UP-UP

4шт.

4

419-06-23310

BRACKET, L.H. - COMBINATION LIGHT

SN: A30001-UP-UP

1шт.

|$8

01435-01020

BOLT, MOUNT COMBINATION LIGHT BRACKET

SN: A30001-UP-UP

4шт.

5

419-06-23320

BRACKET, R.H. - COMBINATION LIGHT

SN: A30001-UP-UP

1шт.

|$10

01435-01020

BOLT, MOUNT COMBINATION LIGHT BRACKET

SN: A30001-UP-UP

4шт.

6

421-06-23430

PLATE, BACKING

SN: A30001-UP-UP

2шт.

7

01435-00816

BOLT, MOUNT BACKING PLATE

SN: A30001-UP-UP

8шт.

8

23S-71-22822

SPRING

SN: A30001-UP-UP

4шт.

9

08037-03614

GROMMET

SN: A30001-UP-UP

4шт.

10

421-06-23310

LIGHT ASSEMBLY, REAR WORK

SN: A30001-UP-UP

2шт.

|$16

421-06-23330

BULB, 70 W

SN: A30001-UP-UP

1шт.

|$17

421-06-23340

LENS

SN: A30001-UP-UP

1шт.

|$18

08056-00271

CONNECTOR

SN: A30001-UP-UP

1шт.

11

01643-31445

WASHER, FLAT

SN: A30001-UP-UP

2шт.

12

01602-21442

WASHER, LOCK

SN: A30001-UP-UP

1шт.

13

01582-11411

NUT

SN: A30001-UP-UP

1шт.
