Запчасти Komatsu WA420-3L FIG. B-A ДВИГАТЕЛЬ И АКСЕССУАРЫ КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

ENGINE ASSEMBLY (SEE FIG. A9101-A3A9)

SN: A30001-UP-UP

-1шт.

2

MOTOR ASSEMBLY, STARTING(SEE FIG. B6210-B2A6)

SN: A30001-UP-UP

-1шт.

|$2

01010-81245

BOLT, MOUNTING STARTING MOTOR

SN: A30001-UP-UP

3шт.

|$3

01643-31232

WASHER

SN: A30001-UP-UP

3шт.

|$4

1211 455 H2

GASKET, STARTING MOTOR

SN: A30001-UP-UP

1шт.

3

ALTERNATOR, 50 A (SEE FIG. B0020-01A1)

SN: A30001-UP-UP

-1шт.

4

206-01-A1140

SENSOR ASSEMBLY, ENGINE OIL LEVEL

SN: A30001-UP-UP

1шт.

|$7

206-01-A1160

SENSOR, ENGINE OIL LEVEL

SN: A30001-UP-UP

1шт.

|$8

1209 470 H1

CONNECTOR, MALE

SN: A30001-UP-UP

1шт.

|$9

1209 477 H1

SEAL, TERMINAL

SN: A30001-UP-UP

4шт.

|$10

1209 466 H1

TERMINAL

SN: A30001-UP-UP

4шт.

5

206-01-A1150

SWITCH, ENGINE OIL PRESSURE

1шт.

|$13

OR

-1шт.

5

1312 855 H1

SWITCH, ENGINE OIL PRESSURE

1шт.

6

206-01-A1130

SENSOR, ENGINE COOLANT TEMPERATURE

SN: A30001-UP-UP

1шт.

|$17

24 466 R1

BUSHING, REDUCER - 3/4 X 1/2 IN.

SN: A30001-UP-UP

1шт.

7

MUFFLER (SEE FIG. B0000-05A0)

SN: A30001-UP-UP

-1шт.

8

CLEANER ASSEMBLY, AIR(SEE FIG. B0000-04A0)

SN: A30001-UP-UP

-1шт.

9

421-01-A1160

FAN, BLOWER - ENGINE

SN: A30001-UP-UP

1шт.

10

1237 716 H1

SPACER, FAN PILOT

SN: A30001-UP-UP

1шт.

|$22

01011-81015

BOLT, FAN MOUNTING

SN: A30001-UP-UP

4шт.

|$23

25 536 R1

WASHER

SN: A30001-UP-UP

4шт.

11

419-06-21320

PLATE

SN: A30001-UP-UP

1шт.

12

01435-01220

BOLT

SN: A30001-UP-UP

2шт.

13

419-06-21310

RELAY, STARTER DISABLE

SN: A30001-UP-UP

1шт.

14

01435-00616

BOLT

SN: A30001-UP-UP

2шт.

N/I

421-01-A1170

SWITCH, STARTER RELAY

SN: A30001-UP-UP

1шт.

N/I

421-06-A1170

BRACKET, RELAY MOUNTING

SN: A30001-UP-UP

1шт.
