Запчасти Komatsu WA420-3L FIG. K7-8A КОНДИЦ. ВОЗДУХА - CМАСЛ. КОРПУС КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

419-963-A100

BOX ASSEMBLY, COIL - A/C AND HEATER

SN: A30001-UP-UP

1шт.

1

419-942-A470

BOX, COIL - A/C AND HEATER

SN: A30001-UP-UP

1шт.

2

419-942-A420

BRACKET, COIL

SN: A30001-UP-UP

1шт.

3

419-942-A410

COVER, COIL BOX

SN: A30001-UP-UP

1шт.

4

416-942-A980

WASHER, LOCK - 1/4 IN.

SN: A30001-UP-UP

2шт.

5

NSS

BOLT - M6-1

SN: A30001-UP-UP

2шт.

6

NSS

NUT, BULKHEAD

SN: A30001-UP-UP

2шт.

7

418-T42-A390

SCREW - NO. 10-32

SN: A30001-UP-UP

8шт.

8

418-T42-A470

SCREW - 1/4

SN: A30001-UP-UP

5шт.

9

NSS

O-RING

SN: A30001-UP-UP

2шт.

10

419-942-A540

COIL, HEAT

SN: A30001-UP-UP

1шт.

11

419-963-AA40

COIL, EVAPORATOR

SN: A30001-UP-UP

1шт.

12

NSS

FOAM, COIL COVER

SN: A30001-UP-UP

1шт.

13

NSS

FOAM, DRAIN PAN

SN: A30001-UP-UP

1шт.

14

NSS

FOAM, FAN SIDE

SN: A30001-UP-UP

1шт.

15

NSS

FOAM, FILTER SIDE

SN: A30001-UP-UP

1шт.

16

425-963-AB50

SWITCH, THERMOSTAT

SN: A30001-UP-UP

1шт.

17

1303 672 H1

VALVE, EXPANSION

SN: A30001-UP-UP

1шт.

18

1434 308 H1

O-RING

SN: A30001-UP-UP

2шт.

19

1432 111 H1

SWITCH, LOW-PRESSURE

SN: A30001-UP-UP

1шт.

20

425-963-AA90

RELAY, AIR CONDITIONER

SN: A30001-UP-UP

1шт.

21

416-942-A940

PLUG

SN: A30001-UP-UP

1шт.

22

416-942-A450

PLUG

SN: A30001-UP-UP

1шт.

23

419-963-AA50

HARNESS, AIR CONDITIONER

SN: A30001-UP-UP

1шт.

N/I

BRACKET, TERMINAL BLOCK (SEE FIG. K0710-06A0)

SN: A30001-UP-UP

-1шт.

N/I

VALVE, WATER (SEE FIG. K0713-01A1)

SN: A30001-UP-UP

-1шт.

N/I

419-942-A500

KIT, HARDWARE

SN: A30001-UP-UP

1шт.

N/I

419-942-A400

KIT, FOAM

SN: A30001-UP-UP

1шт.

|$28

-1шт.

|$29

F1 - INCLUDED IN HARDWARE KIT.

-1шт.

|$31

-1шт.

|$32

F2 - INCLUDED IN FOAM KIT.

-1шт.

|$33

-1шт.
