Запчасти Komatsu WA420-3L FIG. K-7A КАБИНА ROPS - ЗАДН. СТЕКЛА И ДВОРНИКИ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

CAB ASSEMBLY, ROPS(SEE FIG. K0210-10A0)

SN: A30001-UP-UP

-1шт.

1

421-926-2510

GLASS, REAR

SN: A30001-UP-UP

1шт.

2

423-926-A170

SEAL

SN: A30001-UP-UP

1шт.

3

423-926-A250

MOTOR, REAR WIPER - 24 V

SN: A30001-UP-UP

1шт.

4

423-926-A290

DRIVE, ARM

SN: A30001-UP-UP

1шт.

5

423-926-A460

BRACKET, MOUNT WIPER MOTOR

SN: A30001-UP-UP

1шт.

|$6

01435-00610

BOLT, BRACKET MOUNTING

SN: A30001-UP-UP

4шт.

6

423-926-A330

LINK, REAR WIPER

SN: A30001-UP-UP

1шт.

7

423-926-A370

SHAFT ASSEMBLY, WIPER - 1 IN.

SN: A30001-UP-UP

1шт.

8

417-927-AE60

KIT, PANTO ADAPTER

SN: A30001-UP-UP

1шт.

|$10

363-06-35410

BOLT, PANTO ADAPTER MOUNTING

SN: A30001-UP-UP

2шт.

9

423-926-A240

HARNESS, REAR WIPER MOTOR

SN: A30001-UP-UP

1шт.

10

417-927-AL70

FITTING, COWL

SN: A30001-UP-UP

1шт.

11

423-926-A380

KIT, WASHER - WET ARM

SN: A30001-UP-UP

1шт.

12

423-926-A360

ARM, REAR WIPER - 22 IN.

SN: A30001-UP-UP

1шт.

13

423-926-A340

BLADE, REAR WIPER - 18 IN.

SN: A30001-UP-UP

1шт.

14

423-926-A010

CAP

SN: A30001-UP-UP

1шт.

15

01220-70412

SCREW

SN: A30001-UP-UP

2шт.

|$18

-1шт.

|$19

F1 - WHEN REPLACED BY ROPS CAB HARNESS P/N 419-926-A840, REAR WIPERHARNESS P/N 423-926-A240 AND FRONT WIPER HARNESS P/N 423-926-A190ARE NO LONGER REQUIRED. (SEE FIG. K0210-06A0)

-1шт.

|$20

-1шт.
