Запчасти Komatsu WA420-3L FIG. H-8A ГИДР. НАСОС. - ТРАНСМИССИЯ НАГНЕТАЮЩ. НАСОС ГИДРАВЛИКА

|$0

705-22-40070

PUMP ASSEMBLY, CHARGING - SAR100

SN: A30001-UP-UP

2шт.

1

705-17-03022

BRACKET

SN: A30001-UP-UP

1шт.

|$2

705-17-03352

BUSHING, PLANE

SN: A30001-UP-UP

2шт.

2

705-17-40010

CASE, GEAR

SN: A30001-UP-UP

1шт.

3

705-17-03121

COVER

SN: A30001-UP-UP

1шт.

|$5

705-17-03352

BUSHING, PLANE

SN: A30001-UP-UP

2шт.

4

705-17-40370

GEAR, DRIVE

SN: A30001-UP-UP

1шт.

5

705-17-40510

GEAR, DRIVEN

SN: A30001-UP-UP

1шт.

6

705-17-03610

PLATE, SIDE

SN: A30001-UP-UP

2шт.

7

705-17-03473

SEAL

SN: A30001-UP-UP

2шт.

8

705-17-03440

RING, BACK-UP

SN: A30001-UP-UP

2шт.

9

705-17-03381

O-RING

SN: A30001-UP-UP

2шт.

10

04020-01228

PIN, DOWEL

SN: A30001-UP-UP

4шт.

11

01253-61635

BOLT

SN: A30001-UP-UP

4шт.

12

01643-51645

WASHER

SN: A30001-UP-UP

4шт.

13

705-17-03810

SEAL, OIL

SN: A30001-UP-UP

1шт.

14

705-17-03870

PLATE

SN: A30001-UP-UP

1шт.

15

04065-05220

RING, SNAP

SN: A30001-UP-UP

1шт.

|$18

-1шт.

|$19

F1 - PARTS ARE SUPPLIED SEPARATELY ONLY TO DESIGNATED DEALERSWHICH ARE EQUIPPED WITH A HYDRAULIC PUMP TESTER.

-1шт.

|$20

-1шт.
