Запчасти Komatsu WA420-3CS ТРАНСМИССИЯ (3-Я И 4-Я МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$2

714-17-10010

TRANSMISSION ASS'Y

SN: R50001-UP

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

|$5

714-07-13500

CLUTCH ASS'Y,3RD AND 4TH

SN: R50001-UP

1шт.

1

714-07-13511

SHAFT ASS'Y

SN: R50001-UP

1шт.

2

714-07-12661

PISTON,3RD AND 4TH

SN: R50001-UP

2шт.

3

714-07-12670

DISC

SN: R50001-UP

12шт.

4

714-07-12680

PLATE,SEPARATE

SN: R50001-UP

14шт.

5

714-07-12780

SPRING,WAVE

SN: R50001-UP

12шт.

6

714-07-12711

PLATE,END

SN: R50001-UP

2шт.

7

714-07-12720

RING,SNAP

SN: R50001-UP

2шт.

8

714-07-19320

RING,SEAL

SN: R50001-UP

2шт.

9

714-07-12740

RING,SEAL

SN: R50001-UP

2шт.

10

714-07-12220

WASHER,THRUST

SN: R50001-UP

2шт.

11

714-07-12210

WASHER,THRUST

SN: R50001-UP

2шт.

12

714-07-12930

WASHER,THRUST

SN: R50001-UP

1шт.

13

714-07-12250

SPACER

SN: R50001-UP

2шт.

14

714-07-12271

BEARING,NEEDLE

SN: (101103)-UP

2шт.

14

0

BEARING,NEEDLE

SN: R50001-(101102)

2шт.

15

714-07-12281

BEARING,NEEDLE

SN: (101103)-UP

2шт.

15

0

BEARING,NEEDLE

SN: R50001-(101102)

2шт.

16

714-07-13620

GEAR, 53 TEETH,4TH

SN: R50001-UP

1шт.

17

714-07-13541

GEAR, 43-49 TEETH,3RD

SN: R50001-UP

1шт.

18

06040-06215

BEARING

SN: R50001-UP

1шт.

19

714-07-19340

BEARING,ROLLER

SN: R50001-UP

1шт.

20

714-07-12290

RING,SEAL

SN: R50001-UP

3шт.
