Запчасти Komatsu WA420-3 УДАЛЕНН. УПРАВЛЯЮЩ. КЛАПАН, WAYS УПРАВЛЯЮЩ. КЛАПАН ГИДРАВЛИКА

1

702-16-42004

REMOTE CONTROL VALVE

SN: WA420H30179

1шт.

1A

702-16-42005

REMOTE CONTROL VALVE

SN: WA420H30180-UP

1шт.

2

07043-50312

PLUG

EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit

2шт.

3

SLIDER

EnglischBem: ORDER 702-16-42004 NOTE: Pos. (3) included in Pos. (1) and (1A)

3шт.

4

702-16-51140

DISC

EnglischBem: THICKNESS 0,3 MM NOTE: Pos. (4) included in Pos. (1) and (1A) Ki

8шт.

5

702-16-51150

SPRING

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (1A) Kit

4шт.

6

702-16-52360

SPRING

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (1A) Kit

2шт.

7

702-16-52370

SPRING

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (1A) Kit

2шт.

8

702-16-51161

THRUST PLATE

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (1A) Kit

4шт.

9

702-16-51170

DISC

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (1A) Kit

8шт.

10

702-16-51540

LEVER

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (1A) Kit

3шт.

11

702-16-51550

LEVER

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (1A) Kit

1шт.

12

702-16-51220

BUSHING

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (1A) Kit

4шт.

13

07000-02020

O-RING

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (1A) Kit

4шт.

14

702-16-51270

BOOT

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (1A) Kit

4шт.

15

702-16-51231

PLATE

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (1A) Kit

1шт.

16

702-16-51560

GRUB SCREW

EnglischBem: M 12

1шт.

17

702-16-51561

GRUB SCREW

EnglischBem: M 14

1шт.
