Запчасти Komatsu WA420-3 ГИДРАВЛ-НАСОС ГИДРАВЛИКА

1

705-52-30360

HYDRAULIC PUMP

DeutschDesc: HYDRAULIKPUMPE

1шт.

2

705-12-35240

HYDRAULIC PUMP

DeutschDesc: HYDRAULIKPUMPE

1шт.

3

705-17-03870

RING

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit

1шт.

4

705-17-03811

SEAL

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit

1шт.

5

04065-05220

SNAP RING

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit

1шт.

6

705-17-03610

PLATE

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit

2шт.

7

705-17-03473

SEAL

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit

2шт.

8

705-17-03443

BACK-UP RING

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit

2шт.

9

705-17-03381

O-RING

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit

2шт.

10

04020-01228

DOWEL

EnglischBem: NOTE: Pos. (10) included in Pos. (1) and (2) Kit

4шт.

11

705-17-03740

SCREW

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit

4шт.

12

01643-51645

PLAIN WASHER

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit

4шт.

13

705-17-03330

COUPLING

DeutschDesc: KUPPLUNGSSTUECK

1шт.
