Запчасти Komatsu WA420-3 ТРАНСМИССИЯ (1 МУФТА)(№-) ТРАНСМИССИЯ

|$0

714-17-10010

TRANSMISSION ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271.

-1шт.

|$2

714-17-12010

CLUTCH ASS'Y,FORWARD AND 1ST

SN: 50001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2221 AND 2222.

-1шт.

1

714-07-12661

PISTON,1ST

SN: 50001-UP

1шт.

2

714-07-12740

RING,SEAL

SN: 50001-UP

1шт.

3

714-07-19320

RING,SEAL

SN: 50001-UP

1шт.

4

714-07-12670

DISC

SN: 50001-UP

6шт.

5

714-07-12680

PLATE,SEPARATE

SN: 50001-UP

7шт.

6

714-07-12780

SPRING,WAVE

SN: 50001-UP

6шт.

7

714-07-12711

PLATE,END

SN: 50001-UP

1шт.

8

714-07-12720

RING,SNAP

SN: 50001-UP

1шт.

9

714-07-12760

GEAR, 26 TEETH,1ST

SN: 50001-UP

1шт.

10

714-07-12280

BEARING,NEEDLE

SN: 50001-UP

1шт.

11

714-07-12220

WASHER,THRUST

SN: 50001-UP

2шт.

12

714-07-12250

SPACER

SN: 50001-UP

1шт.

13

06043-00315

BEARING

SN: 50001-UP

1шт.
