Запчасти Komatsu WA420-3 ПОРШЕНЬ И ШАТУН [ДВИГАТЕЛЬ]

1

1240906H91

ROD,ENGINE CONNECTING

Field_1: 21243988-

6шт.

2

1304898H1

SCREW,HEX FLANGE HEAD CA

Field_1: 21243988-

2шт.

3

6742-01-2730

NUT

Field_1: 21243988-

2шт.

4

6742-01-2740

BUSHING

Field_1: 21243988-

1шт.

5

6742-01-2750

BEARING

Field_1: 21243988-

12шт.

|$5

6742-01-5067

PISTON ASS'Y

Field_1: 21243988-

6шт.

6

6732-31-2110

PISTON,ENGINE

Field_1: 21243988-

1шт.

7

6742-01-2780

RING

Field_1: 21243988-

2шт.

8

1241748H92

SET,PISTON RING

Field_1: 21243988-

6шт.

9

6742-01-2800

PIN

Field_1: 21243988-

1шт.

5

6742-01-2810

BEARING,0.010INCH

Field_1: 21243988-

-2шт.

5

6742-01-2820

BEARING,0.020INCH

Field_1: 21243988-

-2шт.

5

6742-01-2830

BEARING,0.030INCH

Field_1: 21243988-

-2шт.

5

6742-01-2840

BEARING,0.040INCH CYLINDER KIT

Field_1: 21243988-

-2шт.

|$14

6742-01-5069

KIT,CYLINDER

Field_1: 21243988-

6шт.

|$15

6742-01-5070

KIT,PISTON

Field_1: 21243988-

1шт.

|$16

6742-01-2860

KIT,LINER

Field_1: 21243988-

1шт.

9

6742-01-2800

PIN,PISTON

Field_1: 21243988-

1шт.
