Запчасти Komatsu WA420-3 СИДЕНЬЕ ОПЕРАТОРА(KAB) [РАМА И ЧАСТИ КОРПУСА]

|$0

418-57-D1110

OPERATOR SEAT ASSY

Field_1: 15100-

1шт.

|$1

0

OPERATOR SEAT ASSY

Field_1: 15001-15099

1шт.

1

198470

BACK COVER KIT

Field_1: 15100-

1шт.

2

183679

BACK FOAM KIT

Field_1: 15100-

1шт.

3

187812

SEAT FRAME KIT

Field_1: 15100-

1шт.

4

180977

SEAT COVER KIT

Field_1: 15100-

1шт.

5

157154

SEAT FOAM KIT

Field_1: 15100-

1шт.

6

180761

KNOB KIT

Field_1: 15100-

1шт.

7

188242

FORE & AFT ADJUSTMENT

Field_1: 15100-

1шт.

8

186341

CROSS STRAP KIT

Field_1: 15100-

1шт.

9

174179

WEIGHT ADJUSTER KIT

Field_1: 15100-

1шт.

10

174180

UP-STOP/BUMP STOP KIT

Field_1: 15100-

1шт.

11

198300

DAMPER KIT

Field_1: 15100-

1шт.

12

187889

SUSPENSION KIT

Field_1: 15100-

1шт.

13

174287

RIDE INDICATOR KIT

Field_1: 15100-

1шт.

14

174285

SUSPENSION COVER KIT

Field_1: 15100-

1шт.

15

165216

ARMREST KIT,L.H

Field_1: 15100-

1шт.

16

166386

ARMREST KIT,R.H

Field_1: 15100-

1шт.

17

187077

MECHANICAL LUMBAR KIT

Field_1: 15100-

1шт.
