Запчасти Komatsu WA420-3 ТРАНСМИССИЯ(ПЕРЕД. МУФТА) [ТРАНСМИССИЯ]

|$0

714-17-X0011

TRANSMISSION ASS'Y THIS ASSEMBLY CONSISTS OF ALL PARTS SHOW IN FIGS.2201 TO 2271

Field_1: 15001-

1шт.

|$1

714-17-12010

CLUTCH ASS'Y,FORWARD AND 1ST THIS ASSEMBLY CONSISTS OF ALL PARTS SHOW IN FIGS.2221 TO 2222

Field_1: 15001-

1шт.

1

0

SHAFT ASS'Y

Field_1: 15001-

1шт.

2

714-07-12911

PISTON,FORWARD

Field_1: 15001-

1шт.

3

714-08-19220

RING,SEAL

Field_1: 15001-

1шт.

4

714-07-19320

RING,SEAL

Field_1: 15001-

1шт.

5

714-07-19720

DISC

Field_1: 15001-

10шт.

6

714-07-12680

PLATE,SEPARATE

Field_1: 15001-

11шт.

7

714-07-12690

SPRING,WAVE

Field_1: 15001-

10шт.

8

714-07-12711

PLATE,END

Field_1: 15001-

1шт.

9

714-07-12720

RING,SNAP

Field_1: 15001-

1шт.

10

0

GRAR,49 TEETH.FORWARD

Field_1: 15001-

1шт.

11

56B-15-19420

BEARING,NEEDLE

Field_1: 15001-

2шт.

12

714-07-12220

WASHER,THRUST

Field_1: 15001-

1шт.

13

714-07-12250

SPACER

Field_1: 15001-

1шт.

14

06040-06315

BEARING

Field_1: 15001-

1шт.

15

714-07-12290

RING,SEAL

Field_1: 15001-

3шт.
