Запчасти Komatsu WA420-1LC FIG NO. ТРАНСМИССИЯ ПЕРВ. ПРИВОД МУФТА ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

|$0

TRANSMISSION ASSEMBLY (SEE PG 02-008)

-29шт.

|$1

424-15-00130

CAGE ASSEMBLY

a

1шт.

|$2

424-15-00131

CAGE ASSEMBLY

b

1шт.

1

NSS

CAGE

1шт.

2

234-15-12790

PLUG

2шт.

3

07018-10753

RING, SEAL

2шт.

4

175-15-31210

PIN

1шт.

5

01010-81255

BOLT - MOUNT CAGE TO TRANSMISSION CASE

6шт.

6

01643-31232

WASHER

6шт.

7

06000-06013

BEARING, BALL

1шт.

8

07018-21606

RING, SEAL

a

2шт.

8

424-15-19210

RING, SEAL

b

2шт.

9

421-15-12390

BUSHING

1шт.

10

04260-00635

BALL

1шт.

11

04071-00200

RING, RETAINING

1шт.

12

06000-06928

BEARING, BALL

1шт.

13

04070-00140

RING, RETAINING

1шт.

14

424-15-12351

HOUSING, 1ST CLUTCH

1шт.

15

424-15-12271

GEAR

1шт.

16

424-15-12781

PISTON, 1ST CLUTCH

1шт.

17

562-15-19330

RING, SEAL - 1ST CLUTCH

1шт.

18

113-15-12870

RING, SEAL - 1ST CLUTCH

1шт.

19

424-15-12710

DISC, CLUTCH

2шт.

20

424-15-12720

PLATE, CLUTCH

1шт.

21

421-15-11290

PIN

10шт.

22

125-15-32910

SPRING

10шт.

23

421-15-11280

PIN

5шт.

24

175-15-42880

RING, SPRING

10шт.

25

04020-01228

PIN, DOWEL

2шт.

26

01010-81475

BOLT - MOUNT 1ST CLUTCH HOUSING

9шт.

27

145-14-11570

WASHER

9шт.

28

CARRIER (SEE PG 02-022)

-29шт.

29

SHAFT (SEE PG 02-022)

-29шт.

|$43

-1шт.

|$34

F1 - USED ON MACHINES S/N A25001 THRU A25026 WITH TRANSMISSION S/N UP

-1шт.

|$35

TO 4850. FOR SERVICE, ORDER P/N 424-15-00131, CAGE ASSEMBLY.

-1шт.

|$44

-1шт.

|$37

F2 - USED ON MACHINES S/N A25027 AND UP WITH TRANSMISSION S/N 4851

-1шт.

|$38

AND UP. TO IMPROVE LUBRICATION, THE NEW SEAL RING HAS TEN

-1шт.

|$39

GROOVES ON ONE SIDE INSTEAD OF FIVE, AND THE NEW CAGE HAS A

-1шт.

|$40

LUBRICATION HOLE DRILLED.

-1шт.

|$45

-1шт.

|$42

F3 - ALSO INCLUDED IN SERVICE KIT 424-15-05121.

-1шт.

|$46

-1шт.
