Запчасти Komatsu WA420-1LC FIG NO. ЭЛЕКТР. ДАТЧИКS КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

1

7819-11-2310

SENSOR SPEED

1шт.

|$1

7826-01-1550

GROMMET, SENSOR

1шт.

|$2

7861-01-3170

CAP, SENSOR

1шт.

|$3

7816-11-4780

O-RING, SENSOR

1шт.

|$4

7816-11-4790

TERMINAL, SENSOR

2шт.

2

7861-91-3330

SENSOR, TRANSMISSION OIL TEMPERATURE

1шт.

3

SENSOR, COOLANT LEVEL (SEE PG 01-038)

-29шт.

4

SENSOR, FUEL LEVEL (SEE PG 01-040)

-29шт.

5

SENSOR, AIR GAUGE (SEE PG 03-058)

-29шт.

6

SENSOR, AIR PRESSURE OR PARKING BRAKE

-1шт.

|$10

(SEE FIG. 3511)

2шт.

7

SENSOR, WHEEL BRAKE CHAMBER (SEE PG 03-080)

-29шт.

8

SWITCH, TRANSMISSION CUT-OFF (SEE PG 03-062)

-29шт.

9

SWITCH, STOP LIGHT (SEE PG 03-062)

-29шт.

10

SENSOR ASSEMBLY, ENGINE OIL LEVEL

-1шт.

|$15

(SEE FIG. 1001A)

1шт.

11

SWITCH, ENGINE OIL PRESSURE (SEE PG 01-004)

-29шт.

12

SENSOR, ENGINE COOLANT TEMPERATURE

-1шт.

|$18

(SEE FIG. 1001A)

1шт.
