Запчасти Komatsu WA420-1LC FIG NO. A ДВИГАТЕЛЬ И АКСЕССУАРЫ КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

|$0

424-01-A1010

ENGINE AND ACCESSORIES

1шт.

1

424-01-A1111

ENGINE ASSEMBLY (SEE PG E9-002)

-29шт.

2

MOTOR ASSEMBLY, CRANKING (SEE PG 01-008)

-29шт.

|$3

421-01-A1170

RELAY, STARTER DISABLE

2шт.

|$4

01435-00816

BOLT

1шт.

|$5

421-06-A1170

BRACKET, RELAY MOUNTING

1шт.

3

ALTERNATOR ASSEMBLY (SEE PG 01-014)

-29шт.

|$7

24 861 R1

BOLT

1шт.

|$8

25 536 R1

WASHER

1шт.

4

206-01-A1140

SENSOR ASSEMBLY, ENGINE OIL LEVEL

1шт.

|$10

206-01-A1160

SENSOR, ENGINE OIL LEVEL

1шт.

|$11

1209 470 H1

CONNECTOR, MALE

1шт.

|$12

1209 477 H1

SEAL, TERMINAL

4шт.

|$13

1209 466 H1

TERMINAL

4шт.

5

206-01-A1150

SWITCH, ENGINE OIL PRESSURE

1шт.

6

206-01-A1130

SENSOR, ENGINE OIL PRESSURE

1шт.

N/I

24 466 R1

BUSHING, REDUCER - 3/4 X 1/2 IN

1шт.

7

MUFFLER, EXHAUST (SEE PG 01-024)

-29шт.

8

CLEANER ASSEMBLY, AIR (SEE PG 01-022)

-29шт.

9

421-01-A1160

FAN, ENGINE

1шт.

10

1237 716 H1

SPACER, FAN PILOT

1шт.

11

01011-51015

BOLT, FAN MOUNTING

4шт.

12

1245 016 H1

PLATE, DEFLECTOR

1шт.

13

HOSE, AIR CLEANER TO TURBOCHARGER

-1шт.

|$24

(SEE FIG. 1011A)

1шт.

|$27

-1шт.

|$26

F1 - SEE ENGINE SECTION FOR SERVICE PARTS.

-1шт.

|$28

-1шт.
