Запчасти Komatsu WA420-1LC БЛОК ЦИЛИНДРОВ ОДИНОЧН. ПОРШЕНЬ ОХЛАЖД-Е ФОРСУНКАS БЛОК ЦИЛИНДРОВ

|$0

1241 258 H92

BLOCK ASSEMBLY, CYLINDER

1шт.

1

NSS

BLOCK, CYLINDER

1шт.

2

1240 888 H1

PLUG, EXPANSION - 1 1/8 IN

1шт.

3

6742-01-1370

PLUG, EXPANSION - 13/16 IN

4шт.

4

6736-21-1830

PLUG, EXPANSION

2шт.

4

6736-21-1830

PLUG, EXPANSION

1шт.

5

6736-21-1810

PLUG, EXPANSION - 58.06 MM

1шт.

6

6742-01-1400

BUSHING, CAMSHAFT

7шт.

7

1240 978 H1

CAP, MAIN BEARING

7шт.

8

6742-01-1420

PLUG, EXPANSION

4шт.

9

1241 018 H1

BOLT - M14 X 2.00 X 128

14шт.

|$11

1241 175 H92

KIT, LINER

6шт.

10

NSS

LINER, CYLINDER

1шт.

11

6742-01-1520

SEAL, RECTANGULAR RING

1шт.

12

6216-94-3450

DRAINCOCK - 1/4 NPT

1шт.

13

1240 889 H1

PLUG, EXPANSION - 1 3/16 IN

2шт.

14

6732-11-1910

PLUG, PIPE - 1/2 NPT

4шт.

15

6732-11-1920

PLUG, PIPE - 3/4 NPT

1шт.

16

6742-01-1460

PLUG, PIPE - 1 NPT

1шт.

17

6732-21-6120

DOWEL, PIN - 10 X 16 MM

2шт.

18

6742-01-1470

DOWEL, PIN

4шт.

19

6742-01-1480

PLUG, EXPANSION

1шт.

20

6742-01-0930

NOZZLE, PISTON COOLING - PLASTIC

a

6шт.

20

1240 986 H1

NOZZLE, PISTON COOLING - BRASS

b

6шт.

21

6732-11-1930

PLUG, PIPE - 1/8 NPT

6шт.

|$25

1296 695 H1

SHIM, COUNTERBORE SERVICE - 0.010 OS

-2шт.

|$26

1296 696 H1

SHIM, COUNTERBORE SERVICE - 0.015 OS

-2шт.

|$27

1296 697 H1

SHIM, COUNTERBORE SERVICE - 0.020 OS

-2шт.

|$28

1304 946 H1

BUSHING - OVERSIZE CAM BUSHING

-2шт.

|$29

1258 620 H91

KIT, CYLINDER BLOCK

1шт.

|$$31

-1шт.

|$31

F1 - INCLUDED IN CYLINDER BLOCK SERVICE KIT 1258 620 H91.

-1шт.

|$$33

-1шт.

|$$34

-1шт.

|$34

F2 - TO REPLACE THIS BLOCK YOU MUST PURCHASE:

-1шт.

|$35

1295 786 H93

KIT, CYLINDER BLOCK

1шт.

|$36

6732-11-1910

PLUG, PIPE

1шт.

|$37

6242-01-1110

SET, MAIN BEARING

1шт.

|$38

1294 789 H94

BLOCK, CYLINDER

1шт.

|$39

6742-01-3280

BOLT - M14 X 2.00 X 160

14шт.

|$40

6742-01-3270

BOLT - M14 X 2.00 X 80

12шт.

|$41

6742-01-2470

PLUNGER, LUBRICATION OIL PRESSURE REGULATOR

1шт.

|$42

6742-01-2590

PUMP, LUBRICATION OIL

1шт.

|$43

6742-01-5030

GASKET, CYLINDER HEAD

1шт.

|$44

6742-01-1500

KIT, CYLINDER LINER

6шт.

|$$46

-1шт.

|$46

F3 - THICK-WALL CYLINDER LINERS P/N 1295 708 H91 ARE NOT INCLUDED IN

-1шт.

|$47

SERVICE BLOCK KIT P/N 1295 786 H93 OR 1241 789 H94. THEY MUST

-1шт.

|$48

BE ORDERED SEPARATELY.

-1шт.

|$$50

-1шт.

|$50

F4 - WHENEVER SERVICING CYLINDER BLOCKS, HEAD GASKET P/N 1295 449 H1

-1шт.

|$51

MUST BE USED.

-1шт.
