Запчасти Komatsu WA420-1LC ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

1310 823 H91

CYLINDER HEAD ASSEMBLY

1шт.

1

NSS

HEAD, CYLINDER

1шт.

2

1296 803 H1

PLUG, EXPANSION

1шт.

3

6742-01-2920

PLUG, EXPANSION - 1.198 IN

5шт.

4

6736-21-1810

PLUG, EXPANSION - 58.06 MM

2шт.

5

6742-01-3240

GUIDE, VALVE STEM

12шт.

6

1307 586 H1

INSERT, EXHAUST VALVE

6шт.

7

1241 223 H2

INSERT, INTAKE VALVE

6шт.

8

6742-01-2960

PLUG, PIPE - 1/6 NPT

1шт.

9

6732-61-2240

PLUG, PIPE - 1/4 NPT

1шт.

10

6732-11-1910

PLUG, PIPE - 1/2 NPT

2шт.

11

6742-01-0870

SEAL, INTAKE VALVE STEM

6шт.

12

1242 032 H1

SEAL, EXHAUST VALVE STEM

6шт.

|$13

1296 823 H1

INTAKE VALVE ASSEMBLY

6шт.

13

NSS

VALVE, INTAKE

1шт.

14

6742-01-2990

COLLET, INTAKE VALVE

2шт.

|$16

6742-01-3000

EXHAUST VALVE ASSEMBLY

6шт.

15

NSS

VALVE, EXHAUST

1шт.

16

6742-01-2990

COLLET, EXHAUST VALVE

2шт.

17

6732-21-5170

WASHER, SEALING

2шт.

18

6732-21-5220

PLUG, THREADED - M22 X 1.50 X 14

2шт.

19

6742-01-3020

SPRING, VALVE

12шт.

20

6742-01-3030

RETAINER, VALVE SPRING

12шт.

21

1294 847 H2

COUPLING, ELBOW

1шт.

22

6742-01-3280

BOLT, CYLINDER HEAD - M14 X 2.00 X 160

14шт.

23

6742-01-3270

BOLT, CYLINDER HEAD - M14 X 2.00 X 80

12шт.
