Запчасти Komatsu WA420-1LC FIG NO. 98A PROВОЗДУХОВОДЫ GRAPHICS ИСПАНИЯ МАРКИРОВКАS, ИНСТРУМЕНТ & КОМПЛЕКТS

1

421-V00-1121

PRODUCT GRAPHIC, CAUTION - BATTERY INSTRUCTION

1шт.

2

1132 722 C2

PRODUCT GRAPHIC, CAUTION - PRESSURIZED COOLING

-1шт.

|$2

SYSTEM

1шт.

3

644 865 C3

PRODUCT GRAPHIC, CAUTION - HYDRAULIC RESERVOIR

1шт.

4

421-V00-1121

PRODUCT GRAPHIC, CAUTION - BATTERY INSTRUCTION

1шт.

5

423-93-A1220

STRIPE, SIDE - R.H

1шт.

6

424-93-11760

PLATE, MARK - WA420

1шт.

7

423-93-11142

PLATE, STRIPE

1шт.

8

1124 687 C2

PRODUCT GRAPHIC, IMPORTANT - DIESEL FUEL

1шт.

9

419-V00-1140

PRODUCT GRAPHIC, CAUTION - ENGINE FAN

1шт.

10

09690-50280

PLATE, MARK - KOMATSU

2шт.

11

423-93-11142

PLATE, STRIPE

1шт.

12

424-93-11760

PLATE, MARK - WA420

1шт.

13

423-93-A1210

STRIPE, SIDE - L.H

1шт.

14

09152-01000

PRODUCT GRAPHIC, CAUTION - DRAIN AIR TANK

1шт.

15

419-V00-1230

PLATE, DANGER - ARTICULATION AREA

1шт.

16

419-V00-1130

PRODUCT GRAPHIC, DANGER - FRAME LOCKING BAR

1шт.

17

421-V00-1310

PRODUCT GRAPHIC, IMPORTANT - TRANSMISSION

-1шт.

|$18

OIL LEVEL

1шт.

18

09152-01000

PRODUCT GRAPHIC, CAUTION - DRAIN AIR TANK

1шт.

19

424-V00-1210

CHART, OIL

1шт.

20

09152-01000

PRODUCT GRAPHIC, CAUTION - DRAIN AIR TANK

1шт.

21

09690-C0400

PLATE, MARK - KOMATSU

1шт.

22

421-93-11132

PLATE, EQUIPMENT CONTROL LEVER

1шт.

23

09685-00003

PLATE, EQUIPMENT CONTROL LEVER LOCK

1шт.

24

421-V00-1220

PLATE, RELAY POSITION

1шт.

25

421-V00-1230

PLATE, FUSE IDENTIFICATION

1шт.

26

424-V00-1240

PLATE, FUSE IDENTIFICATION

1шт.

27

09683-11070

PLATE, STARTING SWITCH

1шт.

28

NSS

PLATE, PRODUCT IDENTIFICATION

1шт.

N/I

04418-13060

SCREW

4шт.

29

424-V00-1240

PLATE, MONITOR PANEL OPERATION

1шт.

30

1120 095 C2

PRODUCT GRAPHIC, LIFT AND TIE DOWN

4шт.

31

418-V00-1160

PRODUCT GRAPHIC, IMPORTANT - ETHER START

1шт.

32

1132 016 C2

PRODUCT GRAPHIC, ENGINE OIL DRAIN

1шт.

33

423-V00-1320

PLATE, REAR AXLE TRUNNION REMOTE GREASE

1шт.

34

421-93-A1160

PRODUCT GRAPHIC, CAUTION - BATTERY CHARGING

2шт.

35

939 372 C3

PRODUCT GRAPHIC, CAUTION - LADDERS

2шт.

36

423-93-A1230

STRIPE - TOP

1шт.

37

423-93-A1240

STRIPE - HOOD

1шт.

N/I

1170 726 C2

PRODUCT GRAPHIC, EMERGENCY EXIT

1шт.

N/I

743 483 C3

PRODUCT GRAPHIC, ROLLOVER CAUTION

1шт.

N/I

419-V00-1120

PRODUCT GRAPHIC, CAUTION OPERATION

1шт.

N/I

419-V00-1150

PRODUCT GRAPHIC, OPERATOR INSTRUCTION

1шт.

N/I

419-V00-1260

PRODUCT GRAPHIC, TRANSMISSION OIL TEMPERATURE

1шт.

|$47

-1шт.

|$46

F1 - USED WITH OPEN ROPS CANOPY.

-1шт.

|$48

-1шт.
