Запчасти Komatsu WA420-1LC FIG NO. 98 PROВОЗДУХОВОДЫ GRAPHICS АНГЛ. МАРКИРОВКАS, ИНСТРУМЕНТ & КОМПЛЕКТS

1

421-93-A1180

PRODUCT GRAPHIC, CAUTION - BATTERY INSTRUCTION

1шт.

2

204 166 C2

PRODUCT GRAPHIC, CAUTION - PRESSURIZED COOLING

-1шт.

|$2

SYSTEM

1шт.

3

2754 473 R3

PRODUCT GRAPHIC, CAUTION - HYDRAULIC RESERVOIR

1шт.

4

421-93-A1180

PRODUCT GRAPHIC, CAUTION - BATTERY INSTRUCTION

1шт.

5

423-93-A1220

STRIPE, SIDE - R.H

1шт.

6

424-93-11760

PLATE, MARK - WA420

1шт.

7

423-93-11142

PLATE, STRIPE

1шт.

8

1124 685 C3

PRODUCT GRAPHIC, IMPORTANT - DIESEL FUEL

1шт.

9

421-93-A1210

PRODUCT GRAPHIC, CAUTION - ENGINE FAN

1шт.

10

09690-50280

PLATE, MARK - KOMATSU

2шт.

11

423-93-11142

PLATE, STRIPE

1шт.

12

424-93-11760

PLATE, MARK - WA420

1шт.

13

423-93-A1210

STRIPE, SIDE - L.H

1шт.

14

421-93-A1150

PRODUCT GRAPHIC, CAUTION - DRAIN AIR TANK

1шт.

15

423-93-11420

PLATE, DANGER - ARTICULATION AREA

1шт.

16

421-93-A1140

PRODUCT GRAPHIC, DANGER - FRAME LOCKING BAR

1шт.

17

421-93-A1120

PRODUCT GRAPHIC, IMPORTANT - TRANSMISSION

-1шт.

|$18

OIL LEVEL

1шт.

18

421-93-A1150

PRODUCT GRAPHIC, CAUTION - DRAIN AIR TANK

1шт.

19

424-93-11910

CHART, OIL

1шт.

20

421-93-A1150

PRODUCT GRAPHIC, CAUTION - DRAIN AIR TANK

1шт.

21

09690-C0400

PLATE, MARK - KOMATSU

1шт.

22

421-93-11132

PLATE, EQUIPMENT CONTROL LEVER

1шт.

23

09685-00003

PLATE, EQUIPMENT CONTROL LEVER LOCK

1шт.

24

423-93-11930

PLATE, RELAY POSITION

1шт.

25

424-93-11421

PLATE, FUSE IDENTIFICATION

1шт.

26

424-93-11432

PLATE, FUSE IDENTIFICATION

1шт.

27

09683-30070

PLATE, STARTING SWITCH

1шт.

28

NSS

PLATE, PRODUCT IDENTIFICATION

1шт.

N/I

04418-13060

SCREW

4шт.

29

421-93-12320

PLATE, MONITOR PANEL OPERATION

1шт.

30

1120 093 C2

PRODUCT GRAPHIC, LIFT AND TIE DOWN

4шт.

31

421-93-A1110

PRODUCT GRAPHIC, IMPORTANT - ETHER START

1шт.

32

1104 217 C2

PRODUCT GRAPHIC, ENGINE OIL DRAIN

1шт.

33

421-93-12220

PLATE, REAR AXLE TRUNNION REMOTE GREASE

1шт.

34

421-93-A1160

PRODUCT GRAPHIC, CAUTION - BATTERY CHARGING

2шт.

35

161 177 H6

PRODUCT GRAPHIC, CAUTION - LADDERS

2шт.

36

423-93-A1230

STRIPE - TOP

1шт.

37

423-93-A1240

STRIPE - HOOD

1шт.

N/I

1170 724 C2

PRODUCT GRAPHIC, EMERGENCY EXIT

1шт.

N/I

737 993 C3

PRODUCT GRAPHIC, ROLLOVER CAUTION

1шт.

N/I

421-93-A1130

PRODUCT GRAPHIC, CAUTION OPERATION

1шт.

N/I

421-93-A1170

PRODUCT GRAPHIC, OPERATOR INSTRUCTION

1шт.

N/I

421-93-A1220

PRODUCT GRAPHIC, TRANSMISSION OIL TEMPERATURE

1шт.

|$47

-1шт.

|$46

F1 - USED WITH OPEN ROPS CANOPY.

-1шт.

|$48

-1шт.
