Запчасти Komatsu WA420-1LC FIG NO. A ЭЛЕКТРИКА - ЛЕВ. КОНСОЛЬ MACHINES EQUIPPED С КАБИНОЙ КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

1

421-06-12581

HARNESS, WIRING

1шт.

2

RELAY, AIR CONDITIONER (SEE PG 05-152)

-29шт.

3

421-06-16141

SWITCH, FRONT WIPER

a

1шт.

3

421-06-A1120

SWITCH, FRONT WIPER

b

1шт.

4

421-06-16150

SWITCH, REAR WIPER

a

1шт.

4

421-06-A1130

SWITCH, REAR WIPER

b

1шт.

5

08036-01814

CLIP

1шт.

6

01010-81020

BOLT

1шт.

7

01643-31032

WASHER

1шт.

8

08036-10814

CLIP

1шт.

9

01010-81020

BOLT

1шт.

10

01643-31032

WASHER

1шт.

11

421-06-A1140

WIRE, FUSE BOX TO FRONT WIPER

1шт.

12

421-06-A1150

CONNECTOR, WIRE AT FUSE BOX

1шт.

|$39

-1шт.

|$15

F1 - USED ON NEWER MACHINES. S/N BREAK IS UNKNOWN.

-1шт.

|$40

-1шт.

|$41

-1шт.

|$18

F2 - SERVICE PARTS FOR WIRING HARNESS 421-06-12581:

-1шт.

|$42

-1шт.

|$20

HARNESS, WIRING

1шт.

|$21

08021-00400

CONNECTOR - AT RADIO SPEAKER

1шт.

|$22

08022-04001

CONNECTOR - AT RADIO POWER SOURCE AND SPEAKER

2шт.

|$23

08027-02000

TERMINAL - AT REAR WIPER, CAB DOME LIGHT, CAB

-1шт.

|$43

-1шт.

|$25

MOUNTED WORK LIGHT AND RADIO SPEAKER CONNECTORS . 10

-1шт.

|$26

08027-00620

CONNECTOR - AT REAR WIPER AND CAB DOME LIGHT

1шт.

|$27

08027-00420

CONNECTOR - AT CAB MOUNTED WORK LIGHT AND RADIO

-1шт.

|$28

SPEAKER

1шт.

|$29

421-09-11640

CONNECTOR - AT REAR WIPER SWITCH

1шт.

|$30

421-09-11650

TERMINAL - AT FRONT AND REAR WIPER

-1шт.

|$31

SWITCH CONNECTORS

9шт.

|$32

421-09-11660

CONNECTOR - AT FRONT WIPER SWITCH

1шт.

|$33

582-06-11930

TERMINAL - AT FLOOR HARNESS CONNECTOR

12шт.

|$34

22W-07-11980

CONNECTOR - AT FLOOR HARNESS

1шт.

|$35

22W-07-11990

CAP - AT FLOOR HARNESS CONNECTOR

1шт.

|$36

22W-07-12110

O-RING - AT FLOOR HARNESS CONNECTOR

1шт.

|$37

08027-11310

CONNECTOR - AT FLOOR HARNESS

1шт.

|$38

08036-41210

CLIP

1шт.
