Запчасти Komatsu WA420-1LC FIG NO. C КАБИНА - РЕВЕРС POLARITY ДВОРНИКИ МОТОРS КАБИНА MODEL NO. CD - ПЕРЕДН. ДВОРНИКИ РАМА, ЧАСТИ КОРПУСА & SUPERSTRUCTURE

|$0

CAB, OPERATOR'S (SEE PG 05-080)

-29шт.

|$1

421-925-A202

KIT, FRONT WIPER

1шт.

1

421-925-AC31

MOTOR, WIPER

1шт.

|$3

421-925-A250

PIVOT ASSEMBLY, ARM

1шт.

2

NSS

GASKET, PIVOT

1шт.

3

NSS

PIVOT, ARM

1шт.

4

NSS

NUT, ARM - PIVOT

1шт.

5

421-925-A221

ARM, WIPER

1шт.

6

421-925-A230

BLADE, WIPER

1шт.

7

421-925-AC50

WASHER, FLAT

1шт.

8

421-925-AC60

GASKET

1шт.

9

421-925-AC80

NUT, HEX

1шт.

10

421-925-AD60

SEAL, WEATHER

1шт.

11

425-925-A110

DRIVER, WIPER ARM

1шт.

12

425-925-A120

WASHER, LOCK

1шт.

13

131 486

NUT, CROWN

1шт.

14

COVER, FRONT MOUNTING (SEE PG 05-080)

-29шт.

|$34

-1шт.

|$18

F1 - FOR COMPLETE REPLACEMENT OF FRONT WIPER MOTOR KIT, ORDER THE

-1шт.

|$19

FOLLOWING PARTS:

-1шт.

|$20

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$21

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$35

-1шт.

|$23

F2 - USED WITH PIVOT ASSEMBLY WITH 1.00 IN. (25.4 MM) BETWEEN WIPER

-1шт.

|$24

ARM MOUNTS, ORDER THE FOLLOWING PARTS:

-1шт.

|$25

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$26

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$36

-1шт.

|$28

F3 - 1.00 IN. (25.4 MM) BETWEEN WIPER ARM MOUNTS ON PIVOT, ORDER THE

-1шт.

|$29

FOLLOWING PARTS:

-1шт.

|$30

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$31

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$37

-1шт.

|$33

F4 - 1.40 IN. (35.8 MM) BETWEEN WIPER ARM MOUNTS ON PIVOT.

-1шт.

|$38

-1шт.
