Запчасти Komatsu WA400-5L ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ (ВСПОМОГ. ГИДРАВЛИКА РУЛ. УПРАВЛЕНИЯ) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

424-62-32110

TUBE,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

2

07000-13030

O-RING,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

3

01010-80835

BOLT,(FOR AUXILIARY STEERING)

SN: A40001-UP

4шт.

4

01643-30823

WASHER,(FOR AUXILIARY STEERING)

SN: A40001-UP

4шт.

5

01435-01016

BOLT,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

6

421-06-35111

SWITCH,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

|$6

424-875-1680

PLUG,(FOR W/O. AUXILIARY STEERING)

SN: A40001-UP

1шт.

7

421-62-32672

VALVE,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

8

07002-13034

O-RING,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

9

421-62-32682

UNION,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

10

07002-13034

O-RING,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

11

02896-11018

O-RING,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

12

02753-006A5

HOSE,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

13

419-U45-1220

PROTECTOR,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

14

02783-10628

ELBOW,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

|$15

07040-12412

PLUG,(FOR W/O. AUXILIARY STEERING)

SN: A40001-UP

1шт.

15

07002-12434

O-RING

SN: A40001-UP

1шт.

16

02896-11018

O-RING,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

17

07000-13035

O-RING,(FOR AUXILIARY STEERING)

SN: A40001-UP

1шт.

|$19

421-62-32351

CHECK VALVE ASS'Y

SN: A40001-UP

1шт.

18

421-62-32360

SPRING

SN: A40001-UP

1шт.

19

702-13-22911

BODY

SN: A40001-UP

1шт.

20

702-13-22921

POPPET

SN: A40001-UP

1шт.

21

702-13-22931

PLATE

SN: A40001-UP

1шт.

22

708-25-12380

BOLT

SN: A40001-UP

1шт.

23

07000-23035

O-RING

SN: A40001-UP

1шт.

24

07000-13035

O-RING

SN: A40001-UP

1шт.

25

01011-81010

BOLT

SN: A40001-UP

4шт.

26

01643-51032

WASHER

SN: A40001-UP

4шт.

27

PUMP ASS'Y,(SEE FIG. F4300-01A0)

SN: A40001-UP

-1шт.

28

TUBE,(SEE FIG. H0210-02A0)

SN: A40001-UP

-1шт.

29

TUBE,(SEE FIG. H0210-02A0)

SN: A40001-UP

-1шт.

30

20D-62-17150

O-RING,(FOR W/O. AUXILIARY STEERING)

SN: A40001-UP

1шт.
