Запчасти Komatsu WA400-5L ОСНОВН. КОНСТРУКЦИЯ (ПРЕДОХРАНИТЕЛЬ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

421-06-32461

FUSE BOX

SN: A40001-UP

1шт.

2

283-06-16190

FUSE, 10A

SN: A40001-UP

13шт.

3

22W-06-13160

FUSE, 20A

SN: A40001-UP

6шт.

4

283-06-16120

COVER

SN: A40001-UP

1шт.

5

421-06-32471

FUSE BOX

SN: A40001-UP

1шт.

6

283-06-16190

FUSE, 10A,(FOR STD. OR JOYSTICK STR.)

SN: A40001-UP

12шт.

|$$7

QUANTITY OF 11 FOR JRB WITH OR WITHOUT AUXILIARY STEERING. QUANTITY OF 12 FOR STANDARD OR JOYSTICK STEERING.

-1шт.

7

22W-06-13160

FUSE, 20A

SN: A40001-UP

7шт.

8

283-06-16120

COVER

SN: A40001-UP

1шт.

9

01023-60516

SCREW,(FOR JRB COUPLER)

SN: A40001-UP

4шт.

|$$11

FOR JRB WITH OR WITHOUT AUXILIARY STEERING.

-1шт.

|$11

01220-40516

SCREW,(FOR STD. OR JOYSTICK STR.)

SN: A40001-UP

4шт.

|$$13

FOR STANDARD OR JOYSTICK STEERING.

-1шт.

10

BRACKET,(SEE FIG. K4200-21A0)

SN: A40001-UP

-1шт.

11

01641-20508

WASHER,(FOR STD. OR JOYSTICK STR.)

SN: A40001-UP

4шт.

|$$16

FOR STANDARD OR JOYSTICK STEERING.

-1шт.

12

283-06-16180

FUSE, 5A,(FOR JRB COUPLER)

SN: A40001-UP

1шт.

|$$18

5A FUSE FOR JRB COUPLER - 10A FUSE FOR STANDARD.

-1шт.
