Запчасти Komatsu WA400-5 КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$3

714-12-20203

TORQFLOW ASS'Y

SN: 70001-UP

1шт.

|$4

0

TORQFLOW ASS'Y

SN: (70001-(110159))

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$6

714-12-20213

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 70001-UP

1шт.

|$7

0

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: (70001-(110159))

1шт.

|$$7

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A2.

-1шт.

|$17

714-07-25401

VALVE ASS'Y

SN: (110077)-UP

1шт.

|$18

0

VALVE ASS'Y

SN: 70001-(110076)

1шт.

|$19

714-07-25461

BODY

SN: (110077)-UP

1шт.

|$20

714-07-25460

BODY

SN: 70001-(110076)

1шт.

1

714-07-25151

BODY

SN: (110077)-UP

1шт.

1

714-07-25150

BODY

SN: 70001-(110076)

1шт.

2

07042-80108

PLUG

SN: (110077)-UP

2шт.

2

07043-70108

PLUG

SN: 70001-(110076)

2шт.

3

714-07-15410

VALVE

SN: 70001-UP

1шт.

4

714-07-15420

SPRING

SN: 70001-UP

1шт.

5

714-07-15430

CHOKE

SN: 70001-UP

1шт.

6

714-07-15840

COVER

SN: 70001-UP

2шт.

7

01010-80820

BOLT

SN: 70001-UP

4шт.

8

01643-30823

WASHER

SN: 70001-UP

4шт.

9

07000-73030

O-RING (K2)

SN: 70001-UP

2шт.
