Запчасти Komatsu WA400-5 ТРАНСМИССИЯ (2 И 3 МУФТА) (МОРОЗОУСТОЙЧИВ. СПЕЦ-Я (A) СПЕЦ-Я.) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$2

714-12-20500

TORQFLOW ASS'Y

SN: 70001-UP

1шт.

|$$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-63A0.

-1шт.

|$7

714-12-22032

CLUTCH ASS'Y,2ND AND 3RD

SN: (110150)-UP

1шт.

|$8

714-12-22030

CLUTCH ASS'Y,2ND AND 3RD

SN: 70001-(110149)

1шт.

1

714-12-22133

SHAFT,2ND AND 3RD

SN: (110150)-UP

1шт.

1

714-12-22131

SHAFT AND CYLINDER A,2ND AND 3RD

SN: 70001-(110149)

1шт.

1

0

SHAFT,LOWER

SN: (110150)-UP

1шт.

1

0

SHAFT,LOWER

SN: 70001-(110149)

1шт.

1

0

ORIFICE

SN: 70001-UP

1шт.

1

0

BALL

SN: 70001-UP

2шт.

1

0

HOUSING

SN: (110040)-UP

1шт.

1

0

HOUSING

SN: 70001-(110039)

1шт.

1

0

ORIFICE

SN: 70001-UP

1шт.

2

714-07-22661

PISTON,RANGE

SN: 70001-UP

2шт.

3

714-12-19711

DISC

SN: 70001-UP

14шт.

4

714-16-19730

PLATE,SEPARATE

SN: 70001-UP

16шт.

5

56D-15-12710

SPRING,WAVE

SN: (110054)-UP

14шт.

5

0

SPRING,WAVE

SN: 70001-(110053)

14шт.

6

714-12-12610

PLATE,END

SN: 70001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 70001-UP

2шт.

8

714-16-19220

RING,SEAL (K1)

SN: 70001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 70001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: (110150)-UP

3шт.

10

714-08-19570

WASHER,THRUST

SN: 70001-(110149)

4шт.

11

714-12-39570

THRUST WASHER,THRUST

SN: (110150)-UP

1шт.

12

714-23-19430

BEARING,NEEDLE

SN: 70001-UP

2шт.

13

714-12-22462

GEAR, 53 TEETH

SN: (110150)-UP

1шт.

13

714-12-22461

GEAR, 53 TEETH,2ND

SN: 70001-(110149)

1шт.

14

714-12-22451

GEAR, 40 TEETH,3RD

SN: 70001-UP

1шт.

15

714-12-22532

GEAR, 49 TEETH

SN: (110150)-UP

1шт.

15

714-12-22530

GEAR, 49 TEETH,OUTPUT

SN: 70001-(110149)

1шт.

16

714-12-22541

GEAR, 28 TEETH,4TH

SN: 70001-UP

1шт.

17

14X-14-19123

BEARING

SN: 70001-UP

1шт.

18

714-07-29340

BEARING

SN: (110150)-UP

1шт.

18

714-07-29350

BEARING

SN: 70001-(110149)

1шт.

19

569-15-49530

RING,SNAP

SN: (110150)-UP

1шт.

20

419-15-12122

RING,SEAL (K1)

SN: 70001-UP

3шт.
