Запчасти Komatsu WA400-5 КАБИНА ROPS (РАДИО COVER) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$4

423-926-3012

ROPS CAB ASS'Y

SN: ..-UP

1шт.

|$5

423-926-3011

ROPS CAB ASS'Y

SN: .-..

1шт.

|$6

423-926-3010

ROPS CAB ASS'Y

SN: 70001-.

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A5.

-1шт.

|$8

423-926-3022

ROPS CAB ASS'Y,(E)

SN: ..-UP

1шт.

|$9

423-926-3021

ROPS CAB ASS'Y,(E)

SN: .-..

1шт.

|$10

423-926-3020

ROPS CAB ASS'Y,(E)

SN: 70001-.

1шт.

|$$8

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A6.

-1шт.

|$12

423-926-3032

ROPS CAB ASS'Y,(A)

SN: ..-UP

1шт.

|$13

423-926-3031

ROPS CAB ASS'Y,(A)

SN: .-..

1шт.

|$14

423-926-3030

ROPS CAB ASS'Y,(A)

SN: 70001-.

1шт.

|$$12

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A7.

-1шт.

|$16

423-926-3042

ROPS CAB ASS'Y,(A+E)

SN: ..-UP

1шт.

|$17

423-926-3041

ROPS CAB ASS'Y,(A+E)

SN: .-..

1шт.

|$18

423-926-3040

ROPS CAB ASS'Y,(A+E)

SN: 70001-.

1шт.

|$$16

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A1.

-1шт.

|$$17

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|$$18

A = AIR CONDITIONER

-1шт.

|$$19

E = LOAD METER

-1шт.

1

421-925-3510

COVER,RADIO

SN: 70001-UP

1шт.

2

01023-60412

SCREW

SN: 70001-UP

2шт.

3

01640-20408

WASHER

SN: 70001-UP

2шт.

4

01580-00403

NUT

SN: 70001-UP

2шт.

5

421-06-36142

SWITCH

SN: 70023-UP

1шт.

5

421-06-36141

SWITCH

SN: 70001-70022

1шт.

5

421-06-36191

LAMP

SN: 70023-UP

1шт.

5

421-06-36190

LAMP

SN: 70001-70022

1шт.

6

42C-56-12310

CAP

SN: 70001-UP

7шт.
