Запчасти Komatsu WA400-3A ТРАНСМИССИЯ (ВПЕРЕД, 1-Я МУФТА) (ДЛЯ ЭКСТРЕННОГО УПРАВЛЕНИЯ) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-17-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 54001-UP

1шт.

|1

714-17-10050

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 53001-54000

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-69A1.

-1шт.

|1

714-17-12010

CLUTCH ASS'Y,FORWARD AND 1ST

SN: 53001-UP

1шт.

1

714-17-12110

SHAFT ASS'Y

SN: 53001-UP

1шт.

2

714-07-12911

PISTON,FORWARD

SN: 53001-UP

1шт.

3

714-07-12661

PISTON,1ST

SN: 53001-UP

1шт.

4

714-07-12670

DISC

SN: 53001-UP

6шт.

5

714-07-19720

DISC

SN: 53001-UP

10шт.

6

714-07-12680

PLATE,SEPARATE

SN: 53001-UP

18шт.

7

714-07-12691

SPRING,WAVE

SN: .-UP

10шт.

|7

0

SPRING,WAVE

SN: 53001-.

10шт.

8

714-07-12780

SPRING,WAVE

SN: 53001-UP

6шт.

9

714-07-12711

PLATE,END

SN: 53001-UP

2шт.

10

714-07-12720

RING,SNAP

SN: 53001-UP

2шт.

11

714-07-19320

RING,SEAL

SN: 53001-UP

2шт.

12

714-08-19220

RING,SEAL

SN: 53001-UP

1шт.

13

714-07-12740

RING,SEAL

SN: 53001-UP

1шт.

14

714-07-12220

WASHER,THRUST

SN: 53001-UP

4шт.

15

714-07-12250

SPACER

SN: 53001-UP

2шт.

16

56B-15-19420

BEARING,NEEDLE

SN: (101565)-UP

3шт.

|16

714-07-12281

BEARING,NEEDLE

SN: (101103)-(101564)

3шт.

|16

0

BEARING,NEEDLE

SN: 53001-(101102)

3шт.

17

714-17-12410

GEAR¤ 49 TEETH,FORWARD

SN: 53001-UP

1шт.

18

714-07-12760

GEAR¤ 26 TEETH,1ST

SN: 53001-UP

1шт.

19

06040-06315

BEARING

SN: 53001-UP

1шт.

20

06043-00315

BEARING

SN: 53001-UP

1шт.

21

714-07-12290

RING,SEAL

SN: 53001-UP

3шт.
