Запчасти Komatsu WA400-3-H МАРКИРОВКА(№-) МАРКИРОВКА

|1

421-93-21112

PLATE KIT

SN: 63001-64001

1шт.

1

0

PLATE¤ SAFETY,RADIATOR CAP

SN: 63001-64001

1шт.

2

0

PLATE¤ CAUTION,BATTERY CABLE

SN: 63001-64001

2шт.

3

0

PLATE¤ CAUTION,ENGINE OIL DRAIN

SN: 63001-64001

1шт.

4

0

PLATE¤ CAUTION,SAFETY BAR

SN: 63001-64001

1шт.

5

0

PLATE¤ CAUTION,KEEP OUT

SN: 63001-64001

2шт.

6

0

PLATE¤ INSTRUCTION,FUEL

SN: 63001-64001

1шт.

7

0

PLATE¤ INSTRUCTION,RADIATOR DRAIN

SN: 63001-64001

1шт.

8

0

PLATE¤ SAFETY,HYDRAULIC TANK CAP

SN: 63001-64001

1шт.

9

0

PLATE¤ INSTRUCTION,CYLINDER BOTTOM PIN

SN: 63001-64001

1шт.

10

0

PLATE¤ INSTRUCTION,REAR AXLE PIVOT PIN

SN: 63001-64001

1шт.

11

0

PLATE¤ CAUTION,STEERING HOSE

SN: 63001-64001

1шт.

12

424-93-21153

CHART¤ OIL

SN: 64001-@

1шт.

|12

424-93-21152

CHART¤ OIL

SN: 63001-63999

1шт.

13

421-93-21260

PLATE¤ MARK,ACTIVE LOADER

SN: 64001-@

2шт.

|13

421-93-21180

PLATE¤ MARK,AVANCE LOADER

SN: 63001-63999

2шт.

14

424-93-11750

PLATE¤ MARK,WA400

SN: 63001-@

2шт.

15

421-93-21150

PLATE¤ STRIPE,L.H.

SN: 63001-@

1шт.

16

421-93-21160

PLATE¤ STRIPE,R.H.

SN: 63001-@

1шт.

17

421-93-21171

PLATE¤ MARK,KOMATSU

SN: 63001-@

1шт.

18

09806-C0880

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 63001-64001

2шт.

19

09667-A0880

PLATE¤ SAFETY,FAN

SN: 63001-64001

2шт.

20

09807-C0880

PLATE¤ SAFETY,KEEP OUT

SN: 63001-64001

2шт.

21

09960-01001

PLATE¤ MARK,HANDLING

SN: 63001-@

4шт.

22

421-93-21510

PLATE

SN: 63011-@

1шт.

23

421-93-21270

PLATE¤ MARK,HYPER

SN: 64001-@

2шт.
