Запчасти Komatsu WA400-1 МАРКИРОВКА (ЯПОН.)(№-9999) МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

1

426-93-11730

PLATE¤ OPERATING,ENGINE OIL PRESSURE RELAY

SN: 10573-UP

1шт.

2

423-93-11250

PLATE¤ OPERATING,RELAY

SN: 10001-UP

1шт.

3

424-93-11280

PLATE¤ CAUTION,BRAKE OIL

SN: 10001-19999

1шт.

4

09668-00100

PLATE¤ SAFETY,RADIATOR CAP

SN: 10001-@

1шт.

5

09653-00100

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 10001-@

1шт.

6

09694-50280

PLATE¤ MARK,SYMBOL

SN: 10001-@

1шт.

7

424-93-11181

PLATE¤ MARK,WA400

SN: 10001-@

1шт.

8

423-93-11142

PLATE¤ STRIPE

SN: 10001-@

1шт.

9

09101-00100

PLATE¤ INSTRUCTION,FUEL

SN: 10197-19999

1шт.

|9

0

PLATE¤ CAUTION,FUEL

SN: 10001-10196

1шт.

10

362-54-17180

PLATE¤ CAUTION,FAN

SN: 10001-@

1шт.

11

421-93-11370

PLATE¤ OPERATING,MONITOR PANEL

SN: 10001-19999

1шт.

12

09690-50280

PLATE¤ MARK,KOMATSU

SN: 10001-19999

2шт.

13

423-93-11142

PLATE¤ STRIPE

SN: 10001-@

1шт.

14

424-93-11181

PLATE¤ MARK,WA400

SN: 10001-@

1шт.

15

09694-50280

PLATE¤ MARK,SYMBOL

SN: 10001-@

1шт.

16

423-93-11240

PLATE¤ CAUTION,KEEP OUT

SN: 10001-@

2шт.

17

362-54-17230

PLATE¤ CAUTION,HOSE CHANGE

SN: 10001-@

1шт.

18

424-93-11230

PLATE¤ NAME

SN: 10001-@

1шт.

19

424-93-11330

PLATE¤ CAUTION,TRANSMISSION OIL LEVEL

SN: 10001-@

1шт.

20

362-54-17160

PLATE¤ CAUTION,FRAME LOCK

SN: 10001-@

1шт.

21

424-93-11112

CHART¤ OIL

SN: 10961-19999

1шт.

|21

0

CHART¤ OIL

SN: 10001-10960

1шт.

|21

0

CHART¤ OIL

SN: (10001-10459)

1шт.

22

09690-50400

PLATE¤ MARK,KOMATSU

SN: 10001-@

1шт.

23

424-93-11360

PLATE¤ OPERATING,WORK LAMP

SN: 10197-UP

1шт.

24

421-93-12290

PLATE¤ OPERATING,LAMP AND TURN SIGNAL

SN: 11175-UP

1шт.

25

09683-01070

PLATE¤ OPERATING,STARTING SWITCH

SN: 10001-@

1шт.

26

421-93-11132

PLATE¤ OPERATING,BUCKET CONTROL LEVER

SN: 10001-@

1шт.

27

09685-00004

PLATE¤ OPERATING,LEVER LOCK

SN: 10001-19999

1шт.

28

09601-00835

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 10001-@

1шт.

|28

04418-13060

SCREW

SN: 10001-@

4шт.

29

419-93-11420

PLATE¤ CAUTION,BATTERY

SN: 10001-19999

1шт.

30

424-93-11240

PLATE¤ OPERATING,FUSE

SN: 10001-19999

1шт.

31

424-93-11250

PLATE¤ OPERATING,FUSE

SN: 10001-19999

1шт.

32

421-93-11181

PLATE¤ SAFETY,STARTING AND AFTER OPERATING

SN: 10001-@

1шт.

33

424-93-11320

PLATE¤ CAUTION,STARTING AND INSPECTION

SN: 10001-@

1шт.

34

419-93-11890

PLATE¤ CAUTION,TRANSMISSION OIL TEMPERATURE

SN: 10511-19999

1шт.

|34

0

PLATE¤ CAUTION,TRANSMISSION OIL TEMPERATURE

SN: 10001-10510

1шт.

35

09152-00100

PLATE¤ SAFETY,AIR TANK¤ DRAIN

SN: 10001-@

1шт.

36

424-93-11120

PLATE¤ CAUTION,AIR TANK

SN: 10001-19999

2шт.

37

424-93-11120

PLATE¤ CAUTION,AIR TANK

SN: 10001-@

1шт.
