Запчасти Komatsu WA40-3 ОСНОВН. НАСОС (ВНУТР. ЧАСТИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

363-17-31402

PUMP ASS'Y,(A4VG28DA-931-0)

SN: 19001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-01A0 TO Y1610-07A0.

-1шт.

|$$3

THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

UCBA041S9146-0

PUMP ASS'Y,PISTON

SN: 19001-UP

1шт.

2

UCH9118R7702-0

PUMP ASS'Y,GEAR

SN: 19001-UP

1шт.

3

UC1100444396

ORIFICE

SN: 19001-UP

1шт.

4

UC1100440064

HARNESS

SN: 19001-UP

1шт.

5

01252-31025

BOLT

SN: 19001-UP

2шт.

6

0

PLATE, NAME

SN: 19001-UP

1шт.

6

0

SCREW

SN: 19001-UP

2шт.

7

UC1100599083

PACKING

SN: 19001-UP

1шт.
