Запчасти Komatsu WA40-3-CB ROAD SWEEPER (ШИНЫ ТИП) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

363-Z56-3510

SWEEPER ASS'Y

SN: 19001-UP

1шт.

1

363-Z56-3520

SWEEPER ASS'Y (WELDED)

SN: 19001-UP

1шт.

2

363-N90-3321

BRACKET (WELDED)

SN: 19001-UP

1шт.

3

363-N90-3690

PLATE (WELDED)

SN: 19001-UP

2шт.

4

363-N90-3810

PLATE (WELDED)

SN: 19001-UP

4шт.

5

363-N90-3340

BLOCK (WELDED)

SN: 19001-UP

1шт.

6

363-N90-3531

PLATE (WELDED)

SN: 19001-UP

1шт.

7

421-46-12L11

SEAT (WELDED)

SN: 19001-UP

1шт.

8

01573-10205

SEAT (WELDED)

SN: 19001-UP

3шт.

9

362-N30-4190

PLATE (WELDED)

SN: 19001-UP

1шт.

10

417-915-1360

BLOCK (WELDED)

SN: 19001-UP

2шт.

11

01573-10206

SEAT (WELDED)

SN: 19001-UP

1шт.

12

363-N90-3551

SHEET

SN: 19001-UP

1шт.

13

01435-01025

BOLT

SN: 19001-UP

7шт.

14

01584-01008

NUT

SN: 19001-UP

7шт.
