Запчасти Komatsu WA380-7 U-A EXTERIOR ПЛАСТИНЫ И ТАБЛИЧКИS ФРАНЦИЯ МАРКИРОВКА

|$0

423-93-51290

PLATE ASSEMBLY

1шт.

1

NSS

PLATE, REMOTE GREASE, CYLINDER

1шт.

2

NSS

PLATE, REMOTE GREASE, REAR AXLE

1шт.

3

NSS

PLATE, RADIATOR DRAIN

1шт.

4

NSS

PLATE, ENGINE OIL DRAIN

1шт.

5

NSS

PLATE, PARKING BRAKE EMERGENCY RELEASE SWITCH

1шт.

6

NSS

PLATE, PARKING BRAKE EMERGENCY RELEASE CAUTION

1шт.

7

09805-05000

PLATE, CAUTION, FENDER, GETTING ON FENDER

2шт.

8

09812-05000

PLATE, CAUTION, DO NOT APPROACH

2шт.

9

09652-51241

PLATE, CAUTION, DIESEL FUEL

1шт.

10

09659-55000

PLATE, WARNING, EXPLOSION HAZARD, PPC ACCUMULATOR

1шт.

11

09659-55000

PLATE, WARNING, EXPLOSION HAZARD, BRAKE ACCUMULATOR

2шт.

12

09659-55000

PLATE, WARNING, EXPLOSION HAZARD, ECSS ACCUMULATOR

1шт.

13

09667-05001

PLATE, CAUTION, ROTATING OBJECT

2шт.

14

09161-25000

PLATE, WARNING, ARTICULATION LOCK

1шт.

15

09162-25000

PLATE, DANGER, KEEP OFF

2шт.

16

09653-05001

PLATE, WARNING, HIGH TEMPERATURE

1шт.

17

09668-05001

PLATE, WARNING, HOT WATER

2шт.

18

09080-05000

PLATE, WARNING, BATTERY CABLES

2шт.

19

09664-20011

PLATE, DANGER, BATTERY

2шт.

20

20Y-00-41770

PLATE, PRE-FILTER CAUTION

1шт.

21

09963-05001

TAG, DANGER, DO NOT OPERATE

1шт.

22

09642-15000

PLATE, SERVICE INSTRUCTION, ENGINE COOLANT AF-NAC

1шт.
