Запчасти Komatsu WA380-7 U-A EXTERIOR ПЛАСТИНЫ И ТАБЛИЧКИS АНГЛ. МАРКИРОВКА

|$0

423-93-41311

PLATE ASSEMBLY

1шт.

1

NSS

PLATE, REMOTE GREASE, CYLINDER

1шт.

2

NSS

PLATE, REMOTE GREASE, REAR AXLE

1шт.

3

NSS

PLATE, RADIATOR DRAIN

1шт.

4

NSS

PLATE, ENGINE OIL DRAIN

1шт.

5

NSS

PLATE, PARKING BRAKE EMERGENCY RELEASE SWITCH

1шт.

6

NSS

PLATE, PARKING BRAKE EMERGENCY RELEASE CAUTION

1шт.

7

09805-03000

PLATE, CAUTION, GETTING ON FENDER

2шт.

8

423-93-51150

LUBRICATION CHART

1шт.

9

423-93-51110

PLATE, L.H. MACHINE MODEL

1шт.

10

423-93-51120

PLATE, R.H. MACHINE MODEL

1шт.

11

423-93-51130

PLATE, L.H. STRIPE

1шт.

12

423-93-51140

PLATE, R.H. STRIPE

1шт.

13

09690-P1000

DECAL, KOMATSU LOGO

2шт.

14

09812-03000

PLATE, CAUTION, DO NOT APPROACH

2шт.

15

09807-C0883

PLATE, CAUTION, DO NOT APPROACH, WORK EQUIPMENT FALL DOWN

2шт.

16

09960-01601

DECAL, LIFT POINT AND TIE DOWN POINT MARKS

4шт.

17

09652-31241

PLATE, CAUTION, DIESEL FUEL

1шт.

18

09659-53000

PLATE, WARNING, EXPLOSION HAZARD, PPC ACCUMULATOR

1шт.

19

09659-53000

PLATE, WARNING, EXPLOSION HAZARD, BRAKE ACCUMULATOR

2шт.

20

09659-53000

PLATE, WARNING, EXPLOSION HAZARD, ECSS ACCUMULATOR

1шт.

21

09602-10042

PLATE, NAME (LIMITED SUPPLY)

1шт.

22

04418-13060

SCREW

4шт.

23

09667-03001

PLATE, CAUTION, ROTATING OBJECT

2шт.

24

09161-23000

PLATE, WARNING, ARTICULATION LOCK

1шт.

25

09162-23000

PLATE, DANGER, KEEP OFF

2шт.

26

09653-03001

PLATE, WARNING, HIGH TEMPERATURE

1шт.

27

09668-03001

PLATE, WARNING, HOT WATER

2шт.

28

09808-03000

PLATE, WARNING, BATTERY CABLES

2шт.

29

09664-30011

PLATE, DANGER, BATTERY

2шт.

30

20Y-00-41340

PLATE, PRE-FILTER CAUTION

1шт.

31

14X-98-35181

PLATE, REFLECTOR

2шт.

32

09963-03001

TAG, DANGER, DO NOT OPERATE

1шт.

33

09642-13000

PLATE, SERVICE INSTRUCTION, ENGINE COOLANT AF-NAC

1шт.

34

09697-00001

PLATE, BATTERY DISCONNECT SWITCH

1шт.

35

09685-00001

DECAL, SYMBOL, LOCK/UNLOCK

2шт.
