Запчасти Komatsu WA380-7 H-A ГИДР. НАСОС. НАСОС РУЛЕВ. УПРАВЛ-Я (/) ГИДРАВЛИКА

|$11

PUMP, STEERING SEE FIG. H0210-06A0

0

-1шт.

1

07000-B3040

O-RING

1шт.

2

07000-B2014

O-RING

2шт.

3

07000-B1009

O-RING

2шт.

4

708-2L-25480

FILTER

2шт.

5

04020-00616

PIN, DOWEL

2шт.

6

01252-60645

BOLT, HEXAGON SOCKET HEAD

4шт.

7

20B-27-11210

BLEEDER

1шт.

8

723-46-16780

ORIFICE

1шт.

9

708-8E-16160

PLUG

1шт.

10

07002-61023

O-RING

1шт.

|$12

11

-1шт.

|$13

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

12

-1шт.
