Запчасти Komatsu WA380-7 OPERATORґS СИДЕНЬЕ, 3-ТОЧЕЧН., С ОБОГРЕВ-ЛЕМ, ВНУТР. ЧАСТИ, / OPERATORґS СИДЕНЬЕ, 3-ТОЧЕЧН., С ОБОГРЕВ-ЛЕМ

|$1

423-57-51230

Seat Assembly

SN: 10001-UP

1шт.

1

421-57-H0P31

Covering

SN: 10001-UP

1шт.

2

421-57-H0P32

Level Control

SN: 10001-UP

1шт.

3

423-57-H0S02

Suspension Unit

SN: 10001-UP

1шт.

4

423-57-H0S03

Wiring Harness

SN: 10001-UP

1шт.

5

421-57-H0P35

Spring

SN: 10001-UP

1шт.

6

421-57-H0P36

Kit, Wear Parts

SN: 10001-UP

1шт.

7

423-57-H0S06

Suspension Assembly

SN: 10001-UP

1шт.

8

421-57-H0P38

Suspension

SN: 10001-UP

1шт.

9

423-57-H0S08

Bellows

SN: 10001-UP

1шт.

10

421-57-H0P40

Compressor

SN: 10001-UP

1шт.

11

423-57-H0S10

Shock Absorber

SN: 10001-UP

1шт.

12

421-57-H0P42

Air Reservoir

SN: 10001-UP

1шт.

13

421-57-H0P43

Adjuster

SN: 10001-UP

1шт.

14

421-57-H0P00

Thrust Bearing

SN: 10001-UP

1шт.

15

421-57-H0P44

Handle

SN: 10001-UP

1шт.

16

423-57-H0S16

Bolt Kit

SN: 10001-UP

1шт.

17

421-57-H0P47

Secondary Belt

SN: 10001-UP

1шт.

18

421-57-H0P48

Bowden Cable

SN: 10001-UP

1шт.

19

421-57-H0P49

Tube

SN: 10001-UP

1шт.

20

421-57-H0P52

Bowden Cable

SN: 10001-UP

1шт.

21

421-57-H0P53

Bowden Cable

SN: 10001-UP

1шт.

22

20K-57-32810

Operation,Trigger

SN: 10001-UP

1шт.

23

421-57-H0P45

Handle

SN: 10001-UP

1шт.

24

421-57-H0P54

Cover

SN: 10001-UP

1шт.

25

421-57-H0P56

Kit, Small Part, Tube

SN: 10001-UP

1шт.

26

421-57-H0P57

Kit, Small Part, Cover

SN: 10001-UP

1шт.

27

421-57-H0P58

Kit, Small Part, Suspension Unit

SN: 10001-UP

1шт.

28

412-57-H0P59

Kit, Small Part, Suspension

SN: 10001-UP

1шт.

29

421-57-H0P60

Kit, Small Part, Compressor

SN: 10001-UP

1шт.

30

421-57-H0P62

Kit, Small Part, Shock Absorber

SN: 10001-UP

1шт.

31

421-57-H0P63

Kit, Small Parts, Air Reservoir

SN: 10001-UP

1шт.

32

421-57-H0P64

Kit, Small Parts, Level Control

SN: 10001-UP

1шт.

33

423-57-H0S32

Adjuster

SN: 10001-UP

1шт.
