Запчасти Komatsu WA380-6 ПОГРУЗ. НАСОС (/) (SN (KFB)-UP) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

708-1W-00741

PUMP ASSEMBLY, LOADER PUMP

SN: (KFB01395)-UP

1шт.

|$1

\9\708-1W-00740

PUMP ASSEMBLY, LOADER PUMP

SN: (KFB00001)-(KFB01394)

1шт.

|$2

0

PUMP SUBASSEMBLY

SN: (KFB01395)-UP

1шт.

|$3

0

PUMP SUBASSEMBLY

SN: (KFB00001)-(KFB01394)

1шт.

|$4

0

CASE ASSEMBLY

SN: (KFB00001)-UP

1шт.

1

0

CASE, PUMP

SN: (KFB00001)-UP

1шт.

2

0

PLUG

SN: (KFB00001)-UP

9шт.

3

0

SLEEVE

SN: (KFB00001)-UP

1шт.

4

0

RING

SN: (KFB00001)-UP

1шт.

5

708-8E-16160

PLUG

SN: (KFB00001)-UP

1шт.

6

07002-11023

O-RING

SN: (KFB00001)-UP

1шт.

7

07040-11409

PLUG

SN: (KFB00001)-UP

1шт.

8

07002-11423

O-RING

SN: (KFB00001)-UP

1шт.

9

0

O-RING

SN: (KFB00001)-UP

1шт.

10

0

O-RING

SN: (KFB00001)-UP

1шт.

11

0

ORIFICE

SN: (KFB00001)-UP

1шт.

12

0

PIN, DOWEL

SN: (KFB00001)-UP

1шт.

13

0

BOLT

SN: (KFB00001)-UP

4шт.

14

0

WASHER

SN: (KFB00001)-UP

4шт.

15

0

CAP

SN: (KFB00001)-UP

1шт.

16

0

BEARING

SN: (KFB00001)-UP

1шт.

17

0

BALL, RETAINER

SN: (KFB00001)-UP

2шт.

18

0

CAM, ROCKER

SN: (KFB00001)-UP

1шт.

19

0

BALL

SN: (KFB00001)-UP

1шт.

20

0

SHAFT

SN: (KFB00001)-UP

1шт.

21

0

BEARING

SN: (KFB00001)-UP

1шт.

22

0

CASE, SEAL

SN: (KFB00001)-UP

1шт.

23

708-1W-42130

SEAL, OIL

SN: (KFB00001)-UP

1шт.

24

07000-B2060

O-RING

SN: (KFB00001)-UP

1шт.

25

0

SPACER KIT

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.5MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.55MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.6MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.65MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.7MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.75MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.8MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.85MM

SN: (KFB00001)-UP

1шт.

25

0

SPACER, 2.9MM

SN: (KFB00001)-UP

1шт.

26

04065-06825

RING, SNAP

SN: (KFB00001)-UP

1шт.
