Запчасти Komatsu WA380-6 ПОРШЕНЬ И ШАТУН AA ДВИГАТЕЛЬ

|$1

6737-32-3120

ROD, ENGINE CONNECTION

SN: 21692067-UP

6шт.

1

0

ROD, ENGINE CONNECTING

SN: 21692067-UP

1шт.

2

6732-31-3220

BOLT

SN: 21692067-UP

2шт.

3

6732-31-3132

BUSHING

SN: 21692067-UP

1шт.

4

6754-32-3410

BEARING, CONNECTION ROD

SN: 21692067-UP

6шт.

4

6754-32-3420

BEARING, CONNECTING ROD (0.25MM OVERSIZE)

SN: 21692067-UP

-26шт.

4

6754-32-3430

BEARING, CONNECTING ROD (0.50MM OVERSIZE)

SN: 21692067-UP

-26шт.

4

6754-32-3440

BEARING, CONNECTING ROD (0.75MM OVERSIZE)

SN: 21692067-UP

-26шт.

4

6754-32-3450

BEARING, CONNECTING ROD (1.00MM OVERSIZE)

SN: 21692067-UP

-26шт.

5

6732-31-3420

BEARING, CONNECTING ROD (STD)

SN: 21692067-UP

6шт.

5

6738-39-3400

BEARING, CONNECTING ROD (0.25MM OVERSIZE)

SN: 21692067-UP

-26шт.

5

6738-38-3400

BEARING, CONNECTING ROD (0.50MM OVERSIZE)

SN: 21692067-UP

-26шт.

5

6738-37-3400

BEARING, CONNECTING ROD (0.75MM OVERSIZE)

SN: 21692067-UP

-26шт.

5

6738-36-3400

BEARING, CONNECTING ROD (1.00MM OVERSIZE)

SN: 21692067-UP

-26шт.

6

6754-32-2110

PISTON, KIT

SN: 21692067-UP

6шт.

6

0

PISTON

SN: 21692067-UP

1шт.

7

6754-31-2410

PIN, PISTON

SN: 21692067-UP

1шт.

8

6754-31-2010

PISTON RING ASSEMBLY

SN: 21692067-UP

1шт.

9

6732-31-2420

CIRCLIP

SN: 21692067-UP

12шт.
