Артикул
Название
Примечание
Количество
|$0
MOTOR ASSEMBLY (SEE FIG. C0110-02A1)
SN: A54001--UP
-1шт.
3
01252-61255
BOLT
SN: A54001--UP
4шт.
4
708-7S-12330
SHAFT
SN: A54001--UP
1шт.
5
708-7S-12140
BEARING
SN: A54001--UP
1шт.
6
708-7S-12220
BEARING
SN: A54001--UP
1шт.
7
708-7S-05110
SHIM KIT
SN: A54001--UP
1шт.
9
708-1S-11890
SPACER
SN: A54001--UP
1шт.
11
708-7S-13120
BLOCK, CYLINDER
SN: A54001--UP
1шт.
12
708-7S-13250
PLATE, VALVE
SN: A54001--UP
1шт.
13
720-68-19610
PIN
SN: A54001--UP
1шт.
15
708-7S-13530
SPACER
SN: A54001--UP
2шт.
16
708-7S-13560
SPRING
SN: A54001--UP
1шт.
18
708-7S-13550
GUIDE, RETAINER
SN: A54001--UP
1шт.
19
708-7S-13360
RETAINER, SHOE
SN: A54001--UP
1шт.
20
708-7S-13350
PISTON SUBASSEMBLY
SN: A54001--UP
5шт.
21
708-7S-13420
PLATE, THRUST
SN: A54001--UP
1шт.
|$22
22
-1шт.
|$23
F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.
23
-1шт.
Выбрано товаров: 24
