Запчасти Komatsu WA380-6 F-A ТРАНСМИССИЯ 2 И 3 МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION (SEE FIG. F4350-51A0)

SN: A54001--UP

-1шт.

|$27

OR

1

-1шт.

|$2

TRANSMISSION WITH LOCK UP (SEE FIG. F4350-51A1)

SN: A54001--UP

-1шт.

|$3

714-12-32030

CLUTCH

SN: A54001--UP

1шт.

1

714-12-32133

SHAFT AND CYLINDER, 2ND AND 3RD

SN: A54001--UP

1шт.

2

714-12-32662

PISTON, RANGE

SN: A54001--UP

2шт.

3

714-12-19711

DISC

SN: A54001--UP

13шт.

4

714-16-19730

PLATE, SEPARATE

SN: A54001--UP

15шт.

5

56D-15-12710

SPRING, WAVE

SN: A54001--UP

13шт.

6

714-12-12610

PLATE, END

SN: A54001--UP

2шт.

7

419-15-12140

RING, SNAP

SN: A54001--UP

2шт.

8

714-16-19220

RING, SEAL

SN: A54001--UP

2шт.

9

714-07-19320

RING, SEAL

SN: A54001--UP

2шт.

10

714-08-19570

WASHER, THRUST

SN: A54001--UP

3шт.

11

714-23-19431

BEARING

SN: A54001--UP

1шт.

12

714-12-32463

GEAR, 51 TEETH, 2ND

SN: A54001--UP

1шт.

13

714-12-32452

GEAR, 38 TEETH, 3RD

SN: A54001--UP

1шт.

14

714-12-32533

GEAR, 49 TEETH, OUTPUT

SN: A54001--UP

1шт.

15

714-12-32541

GEAR, 27 TEETH, 4TH

SN: A54001--UP

1шт.

16

418-17-39330

BEARING

SN: A54001--UP

1шт.

17

714-07-29340

BEARING

SN: A54001--UP

1шт.

18

714-12-33860

SPACER

SN: A54001--UP

1шт.

19

714-12-12910

SPACER

SN: A54001--UP

1шт.

20

04064-06020

RING

SN: A54001--UP

1шт.

21

714-12-39570

WASHER, THRUST

SN: A54001--UP

1шт.

22

714-12-39220

RING, SEAL

SN: A54001--UP

3шт.

23

714-12-39210

RING, SEAL

SN: A54001--UP

2шт.
