Запчасти Komatsu WA380-6 A-AA7 ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

|$0

6737-32-3120

ROD, ENGINE CONNECTING

6шт.

1

NSS

ROD, ENGINE CONNECTING

1шт.

2

6732-31-3320

SCREW, CONNECTING ROD CAP

1шт.

3

6732-31-3132

BUSHING

1шт.

4

6754-32-3410

BEARING, CONNECTING ROD

6шт.

5

6732-31-3420

BEARING, CONNECTING ROD

6шт.

|$6

6754-32-2110

KIT, ENGINE PISTON, STANDARD

6шт.

6

6754-31-2111

PISTON, ENGINE

1шт.

7

6754-31-2410

PIN, PISTON

1шт.

8

6754-31-2010

SET, PISTON RING

1шт.

N/I

NSS

RING, COMPRESSION PISTON (TOP)

1шт.

N/I

NSS

RING, COMPRESSION PISTON (2ND)

1шт.

N/I

NSS

RING, OIL PISTON

1шт.

9

6732-31-2420

RING, RETAINING

12шт.

10

6754-21-1191

NOZZLE, PISTON COOLING

6шт.

11

6754-21-1180

SCREW, BANJO CONNECTOR

6шт.

|$16

6754-31-2120

KIT, ENGINE PISTON 0.50 MM OVERSIZED

6шт.

6

NSS

PISTON

1шт.

7

6754-31-2410

PIN

1шт.

8

6754-39-2010

SET, PISTONG RING

1шт.

|$20

NSS

RING, COMPRESSION PISTON (TOP)

1шт.

|$21

NSS

RING, COMPRESSION PISTON (2ND)

1шт.

|$22

NSS

RING, OIL PISTON

1шт.

9

6732-31-2420

RING

12шт.

4

6754-32-3420

BEARING, CONNECTING ROD .25 MM OVERSIZE

-2шт.

4

6754-32-3430

BEARING, CONNECTING ROD .50 MM OVERSIZE

-2шт.

4

6754-32-3440

BEARING, CONNECTING ROD .75 MM OVERSIZE

-2шт.

4

6754-32-3450

BEARING, CONNECTING ROD 1.00 MM OVERSIZE

-2шт.

5

6738-39-3400

BEARING, CONNECTING ROD .25 MM OVERSIZE

-2шт.

5

6738-38-3400

BEARING, CONNECTING ROD .50 MM OVERSIZE

-2шт.

5

6738-37-3400

BEARING, CONNECTING ROD .75 MM OVERSIZE

-2шт.

5

6738-36-3400

BEARING, CONNECTING ROD 1.00 MM OVERSIZE

-2шт.
