Запчасти Komatsu WA380-6 ТРАНСМИССИЯ (ОСНОВН. РАЗГРУЗ. КЛАПАН)(№-) ТРАНСМИССИЯ

|$8

714-12-30003

TRANSMISSION ASS'Y

SN: 65628-UP

1шт.

|$9

714-12-30002

TRANSMISSION ASS'Y

SN: 65483-65627

1шт.

|$10

714-12-30001

TRANSMISSION ASS'Y

SN: 65048-65482

1шт.

|$11

714-12-30000

TRANSMISSION ASS'Y

SN: 65001-65047

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-66A0.

-1шт.

|$13

714-12-30013

TRANSMISSION ASS'Y

SN: 65628-UP

1шт.

|$14

714-12-30012

TRANSMISSION ASS'Y

SN: 65483-65627

1шт.

|$15

714-12-30011

TRANSMISSION ASS'Y

SN: 65038-65482

1шт.

|$16

714-12-30010

TRANSMISSION ASS'Y

SN: 65001-65037

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-66A1, F4350-68A1.

-1шт.

|$26

714-24-26001

VALVE ASS'Y

SN: 65001-UP

1шт.

1

0

VALVE BODY

SN: 65001-UP

1шт.

2

708-8E-16150

PLUG

SN: 65001-UP

2шт.

3

07002-61023

O-RING (K2)

SN: 65001-UP

2шт.

4

14X-15-15850

PLUG

SN: 65001-UP

1шт.

5

07002-63034

O-RING (K2)

SN: 65001-UP

1шт.

6

0

VALVE

SN: 65001-UP

1шт.

7

426-15-15490

VALVE

SN: 65001-UP

1шт.

8

198-15-15770

SPRING, (L= 30.0)

SN: 65001-UP

1шт.

9

426-15-15480

VALVE

SN: 65001-UP

1шт.

10

198-15-15570

SHIM, 0.50MM (K2)

SN: 65001-UP

5шт.

11

426-15-16251

SPRING, (L=122.0)

SN: 65001-UP

1шт.

12

426-15-16261

SPRING, (L=108.0)

SN: 65001-UP

1шт.

13

426-15-15810

PLUG

SN: 65001-UP

1шт.

14

07002-63034

O-RING (K2)

SN: 65001-UP

1шт.

15

0

SPOOL

SN: 65001-UP

1шт.

16

104-15-25490

VALVE

SN: 65001-UP

1шт.

17

125-15-15290

SPRING

SN: 65001-UP

1шт.

18

104-15-25480

VALVE

SN: 65001-UP

1шт.

19

14X-15-16210

SPRING

SN: 65001-UP

1шт.

20

12H-15-14140

GUIDE

SN: 65001-UP

1шт.

21

14X-15-15850

PLUG

SN: 65001-UP

2шт.

22

07002-63034

O-RING (K2)

SN: 65001-UP

2шт.

23

175-15-56470

SHIM, 0.50MM (K2)

SN: 65001-UP

2шт.
