Запчасти Komatsu WA380-6 ТРАНСМИССИЯ (2 И 3 МУФТА)(№-) ТРАНСМИССИЯ

Схема запчастей Komatsu WA380-6 - ТРАНСМИССИЯ (2 И 3 МУФТА)(№-) ТРАНСМИССИЯ
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
10
11
11
12
13
14
15
16
17
18
19
20
21
22
23

Артикул

Название

Примечание

Количество

|$8

714-12-30003

TRANSMISSION ASS'Y

SN: 65628-UP

1шт.

|$9

714-12-30002

TRANSMISSION ASS'Y

SN: 65483-65627

1шт.

|$10

714-12-30001

TRANSMISSION ASS'Y

SN: 65048-65482

1шт.

|$11

714-12-30000

TRANSMISSION ASS'Y

SN: 65001-65047

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-66A0.

-1шт.

|$13

714-12-30013

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 65628-UP

1шт.

|$14

714-12-30012

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 65483-65627

1шт.

|$15

714-12-30011

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 65038-65482

1шт.

|$16

714-12-30010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 65001-65037

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A1 TO F4350-66A1, F4350-68A1.

-1шт.

|$32

714-12-32030

CLUTCH,2ND AND 3RD

SN: 65001-UP

1шт.

1

714-12-32133

SHAFT AND CYLINDER A,2ND AND 3RD

SN: 65001-UP

1шт.

1

0

SHAFT,LOWER

SN: 65001-UP

1шт.

1

0

BALL

SN: 65001-UP

2шт.

1

0

HOUSING

SN: 65001-UP

1шт.

1

0

PLUG

SN: 65001-UP

1шт.

2

714-12-32662

PISTON,RANGE

SN: 65001-UP

2шт.

3

714-12-19711

DISC

SN: 65001-UP

13шт.

4

714-16-19730

PLATE,SEPARATE

SN: 65001-UP

15шт.

5

56D-15-12710

SPRING,WAVE

SN: 65001-UP

13шт.

6

714-12-12610

PLATE,END

SN: 65001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 65001-UP

2шт.

8

714-16-19220

RING,SEAL (K1)

SN: 65001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 65001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 65001-UP

3шт.

11

714-23-19431

BEARING

SN: 65001-UP

3шт.

12

714-12-32463

GEAR, 51 TEETH,2ND

SN: 65001-UP

1шт.

13

714-12-32452

GEAR, 38 TEETH,3RD

SN: 65001-UP

1шт.

14

714-12-32533

GEAR, 49 TEETH,OUTPUT

SN: 65001-UP

1шт.

15

714-12-32541

GEAR, 27 TEETH,4TH

SN: 65001-UP

1шт.

16

418-17-39330

BEARING

SN: 65001-UP

1шт.

17

714-07-29340

BEARING

SN: 65001-UP

1шт.

18

714-12-33860

SPACER

SN: 65001-UP

1шт.

19

714-12-12910

SPACER

SN: 65001-UP

1шт.

20

04064-06020

RING

SN: 65001-UP

1шт.

21

714-12-39570

THRUST WASHER,THRUST

SN: 65001-UP

1шт.

22

714-12-39220

SEAL RING,SEAL (K1)

SN: 65001-UP

3шт.

23

714-12-39210

RING,SEAL (K1)

SN: 65001-UP

2шт.

Выбрано товаров: 38
