Запчасти Komatsu WA380-6 КАБИНА ROPS (ПОДСТАКАННИК И CIGARETTE LIGHTER И ПЕПЕЛЬНИЦА)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$18

423-926-0201

ROPS CAB ASS'Y,(EU SPEC.)

SN: 65272-UP

1шт.

|$19

423-926-0200

ROPS CAB ASS'Y,(EU SPEC.)

SN: 65001-65271

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A0 AND K0210-45A0

-1шт.

|$21

423-926-0301

ROPS CAB ASS'Y,(FOR NORTH AMERICA)

SN: 65272-UP

1шт.

|$22

423-926-0300

ROPS CAB ASS'Y,(FOR NORTH AMERICA)

SN: 65001-65271

1шт.

|$$6

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A1 AND K0210-45A0, K0210-46A1.

-1шт.

|$24

421-926-0031

ROPS CAB ASS'Y,(SEPARATE TYPE)

SN: 65272-UP

1шт.

|$25

421-926-0030

ROPS CAB ASS'Y,(SEPARATE TYPE)

SN: 65001-65271

1шт.

|$$9

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A3 TO K0210-14A3. AND K0210-45A0, K0210-46A1.

-1шт.

1

208-53-12991

HOLDER

SN: 65001-UP

1шт.

2

421-926-4780

PLATE

SN: 65001-UP

1шт.

3

426-925-3890

PLATE

SN: 65001-UP

1шт.

4

01023-10616

SCREW

SN: 65001-UP

2шт.

5

20Y-06-23472

CIGARETTE LIGHTER

SN: 65001-UP

1шт.

6

421-926-4710

PLATE

SN: 65001-UP

1шт.

7

20Y-43-41491

ASHTRAY

SN: 65001-UP

1шт.

8

425-926-3751

HOLDER

SN: 65001-UP

1шт.

9

426-925-3890

PLATE

SN: 65001-UP

1шт.

10

421-926-4780

PLATE

SN: 65001-UP

1шт.

11

01023-10614

SCREW

SN: 65001-UP

2шт.
