1
424-62-32110
TUBE,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
2
07000-13030
O-RING,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
3
01010-80835
BOLT,(FOR AUXILIARY STEERING)
SN: A52001-UP
4шт.
4
01643-30823
WASHER,(FOR AUXILIARY STEERING)
SN: A52001-UP
4шт.
5
01435-01016
BOLT,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
6
421-06-35111
SWITCH,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
|$6
424-875-1680
PLUG,(FOR W/O. AUXILIARY STEERING)
SN: A52001-UP
1шт.
7
421-62-32672
VALVE,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
8
07002-13034
O-RING,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
9
421-62-32682
UNION,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
10
07002-13034
O-RING,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
11
02896-11018
O-RING,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
12
02753-006A5
HOSE,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
13
419-U45-1220
PROTECTOR,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
14
02783-10628
ELBOW,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
|$15
07040-12412
PLUG,(FOR W/O. AUXILIARY STEERING)
SN: A52001-UP
1шт.
15
07002-12434
O-RING
SN: A52001-UP
1шт.
16
02896-11018
O-RING,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
17
07000-13035
O-RING,(FOR AUXILIARY STEERING)
SN: A52001-UP
1шт.
|$19
421-62-32351
CHECK VALVE ASS'Y
SN: A52001-UP
1шт.
18
421-62-32360
SPRING
SN: A52001-UP
1шт.
19
702-13-22911
BODY
SN: A52001-UP
1шт.
20
702-13-22921
POPPET
SN: A52001-UP
1шт.
21
702-13-22931
PLATE
SN: A52001-UP
1шт.
22
708-25-12380
BOLT
SN: A52001-UP
1шт.
23
07000-23035
O-RING
SN: A52001-UP
1шт.
24
07000-13035
O-RING
SN: A52001-UP
1шт.
25
01011-81010
BOLT
SN: A52001-UP
4шт.
26
01643-51032
WASHER
SN: A52001-UP
4шт.
27
PUMP ASS'Y,(SEE FIG. F4300-01A0)
SN: A52001-UP
-1шт.
28
TUBE,(SEE FIG. H0210-02A0)
SN: A52001-UP
-1шт.
29
TUBE,(SEE FIG. H0210-02A0)
SN: A52001-UP
-1шт.
30
20D-62-17150
O-RING,(FOR W/O. AUXILIARY STEERING)
SN: A52001-UP
1шт.
