Запчасти Komatsu WA380-5L УПРАВЛЕНИЕ ПОГРУЗКОЙ (2-Х СЕКЦИОНН. РЫЧАГИ) (С ИЛИ БЕЗ ПОГРУЗ. METER) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

421-43-38133

LEVER ASS'Y

SN: A52001-UP

1шт.

1

08023-06050

TUBE

SN: A52001-UP

1шт.

2

421-43-38430

COLLAR

SN: A52001-UP

1шт.

3

08192-24810

CONNECTOR

SN: A52001-UP

1шт.

4

23S-43-51230

GROMMET

SN: A52001-UP

1шт.

5

23S-43-31550

NUT

SN: A52001-UP

1шт.

6

287-43-18350

GROMMET

SN: A52001-UP

1шт.

7

421-43-37591

LEVER

SN: A52001-UP

1шт.

8

421-43-38324

KNOB

SN: A52001-UP

1шт.

|$9

421-43-38512

BODY ASS'Y

SN: A52001-UP

1шт.

|$10

421-43-38590

SWITCH ASS'Y

SN: A52001-UP

1шт.

|$11

421-43-38522

CAP

SN: A52001-UP

1шт.

|$12

421-43-38530

SPACER

SN: A52001-UP

1шт.

|$13

421-43-38540

SPRING

SN: A52001-UP

1шт.

|$14

421-43-38550

CAP

SN: A52001-UP

1шт.

|$15

421-43-38560

RING

SN: A52001-UP

1шт.

|$16

421-43-38570

PLUNGER

SN: A52001-UP

1шт.

|$17

421-43-38580

O-RING

SN: A52001-UP

1шт.

|$18

421-43-38141

LEVER ASS'Y,(WITHOUT LOAD METER)

SN: A52001-UP

1шт.

9

23S-43-31550

NUT,(WITHOUT LOAD METER)

SN: A52001-UP

1шт.

10

421-43-37591

LEVER,(WITHOUT LOAD METER)

SN: A52001-UP

1шт.

11

421-43-38331

KNOB,(WITHOUT LOAD METER)

SN: A52001-UP

1шт.

12

421-43-38430

COLLAR,(WITHOUT LOAD METER)

SN: A52001-UP

1шт.

13

23S-43-51111

LEVER

SN: A52001-UP

2шт.

14

23S-43-51240

NUT

SN: A52001-UP

2шт.

15

01546-10812

NUT,CAP

SN: A52001-UP

2шт.

16

01643-50823

WASHER

SN: A52001-UP

2шт.

17

01010-81035

BOLT

SN: A52001-UP

4шт.

18

421-62-23710

CUSHION

SN: A52001-UP

4шт.

19

421-62-18550

CUSHION

SN: A52001-UP

4шт.

20

175-54-34170

WASHER

SN: A52001-UP

4шт.

21

421-43-31154

PLATE

SN: A52001-UP

1шт.

22

01010-81025

BOLT

SN: A52001-UP

4шт.

23

01643-31032

WASHER

SN: A52001-UP

4шт.

24

421-43-31911

BRACKET

SN: A52001-UP

1шт.

25

01225-70616

SCREW

SN: A52001-UP

4шт.

26

23S-55-51970

WASHER

SN: A52001-UP

4шт.

27

01643-30623

WASHER

SN: A52001-UP

2шт.

28

421-43-31921

COVER

SN: A52001-UP

1шт.

29

01640-20408

WASHER

SN: A52001-UP

4шт.

30

01580-10403

NUT

SN: A52001-UP

4шт.

31

421-43-38720

AWNING

SN: A52001-UP

2шт.

32

PILOT VALVE,(SEE FIG. H4200-24A0)

SN: A52001-UP

-1шт.

33

421-43-38323

KNOB,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$44

421-43-38512

BODY ASS'Y,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$45

421-43-38590

SWITCH ASS'Y,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$46

421-43-38522

CAP,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$47

421-43-38530

SPACER,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$48

421-43-38540

SPRING,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$49

421-43-38550

CAP,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$50

421-43-38560

RING,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$51

421-43-38570

PLUNGER,(WITH LOAD METER)

SN: A52001-UP

1шт.

|$52

421-43-38580

O-RING,(WITH LOAD METER)

SN: A52001-UP

1шт.

34

COVER,(SEE FIG. K4500-01A0)

SN: A52001-UP

-1шт.

|$54

BOX,(SEE FIG. K4500-01A0)

SN: A52001-UP

-1шт.

|$55

421-43-38252

LEVER ASS'Y,(WITH LOAD METER)

SN: A52001-UP

1шт.

35

08023-06050

TUBE,(WITH LOAD METER)

SN: A52001-UP

1шт.

36

421-43-38430

COLLAR,(WITH LOAD METER)

SN: A52001-UP

1шт.

37

08192-24810

CONNECTOR,(WITH LOAD METER)

SN: A52001-UP

1шт.

38

23S-43-51230

GROMMET,(WITH LOAD METER)

SN: A52001-UP

1шт.

39

23S-43-31550

NUT,(WITH LOAD METER)

SN: A52001-UP

1шт.

40

287-43-18350

GROMMET,(WITH LOAD METER)

SN: A52001-UP

1шт.

41

421-43-37591

LEVER,(WITH LOAD METER)

SN: A52001-UP

1шт.
