Запчасти Komatsu WA380-5L ОСНОВН. КОНСТРУКЦИЯ (WRIST REST) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

421-43-31520

REST

SN: A52001-UP

1шт.

2

421-43-31263

BRACKET

SN: A52001-UP

1шт.

3

01435-00616

BOLT

SN: A52001-UP

2шт.

4

421-43-31551

LEVER

SN: A52001-UP

1шт.

5

01580-10806

NUT

SN: A52001-UP

1шт.

6

423-56-21740

KNOB

SN: A52001-UP

1шт.

7

421-43-31353

COVER

SN: A52001-UP

1шт.

|$$8

USED FOR STANDARD, LOADMETER, AND CANOPY ATTACHMENTS.

-1шт.

|$8

421-V91-3320

COVER

SN: A52001-UP

1шт.

|$$10

USED FOR MULTIFUNCTION LEVER OPTION.

-1шт.

|$10

421-V91-3330

COVER

SN: A52001-UP

1шт.

|$$12

USED FOR MULTIFUNCTION LEVER WITH 3-SPOOL OPTION.

-1шт.

|$12

422-V92-A150

COVER

SN: A52001-UP

1шт.

|$$14

USED FOR MULTIFUNCTION LEVER WITH LOADMETER ON WA380 ONLY.

-1шт.

8

421-09-31310

CAP ASS'Y

SN: A52001-UP

4шт.

9

01224-40616

SCREW

SN: A52001-UP

4шт.

10

421-43-31143

PLATE

SN: A52001-UP

1шт.

11

23S-55-51970

WASHER

SN: A52001-UP

4шт.

12

01225-70612

SCREW

SN: A52001-UP

4шт.

13

BRACKET,(SEE FIG. K4500-03A1)

SN: A52001-UP

-1шт.

14

BRACKET,(SEE FIG. K4500-02A0)

SN: A52001-UP

-1шт.

15

LINK,(SEE FIG. K4500-02A0)

SN: A52001-UP

-1шт.

|$22

LINK,(SEE FIG. K4500-02A0)

SN: A52001-UP

-1шт.

16

COVER,(SEE FIG. K4500-01A0)

SN: A52001-UP

-1шт.

|$24

BOX,(SEE FIG. K4500-01A0)

SN: A52001-UP

-1шт.

|$25

BOX,(SEE FIG. K4500-01A0)

SN: A52001-UP

-1шт.
