Запчасти Komatsu WA380-5-TN КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-12-20001

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20000

TRANSMISSION ASS'Y

SN: 60001-(10319)

1шт.

|1

714-12-20011

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 60001-(10319)

1шт.

|1

714-12-20101

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20100

TRANSMISSION ASS'Y,(FOR TACHOGRAPH)

SN: 60001-(10319)

1шт.

|1

714-12-20111

TRANSMISSION ASS'Y

SN: (10320)-UP

1шт.

|1

714-12-20110

TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)

SN: 60001-(10319)

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|1

714-07-25401

VALVE ASS'Y

SN: (110435)-UP

1шт.

|1

0

VALVE ASS'Y

SN: 60001-(110434)

1шт.

|1

714-07-25461

BODY

SN: (110435)-UP

1шт.

|1

714-07-25460

BODY

SN: 60001-(110434)

1шт.

1

714-07-25151

BODY

SN: (110435)-UP

1шт.

|1

714-07-25150

BODY

SN: 60001-(110434)

1шт.

2

07042-80108

PLUG

SN: (110435)-UP

2шт.

|2

07043-70108

PLUG

SN: 60001-(110434)

2шт.

3

714-07-15410

VALVE

SN: 60001-UP

1шт.

4

714-07-15420

SPRING

SN: 60001-UP

1шт.

5

714-07-15430

CHOKE

SN: 60001-UP

1шт.

6

714-07-15840

COVER

SN: 60001-UP

2шт.

7

01010-80820

BOLT

SN: 60001-UP

4шт.

8

01643-30823

WASHER

SN: 60001-UP

4шт.

9

07000-73030

O-RING (K2)

SN: 60001-UP

2шт.
